Yokogawa AGS813-S10 | Isolated Turbomachinery Servo I/O Module

The AGS813-S10 is a Yokogawa servo module for turbomachinery control applications. It combines position feedback, servo command outputs, and discrete quick-close inputs.

The module accepts LVDT signals and standardized 1–5 VDC feedback. It provides isolated current outputs for servo control and 24 VDC digital inputs for quick-close commands.

Its four LVDT channels, four voltage channels, two current outputs, and two digital inputs support integrated actuator control. A 5 ms scan cycle supports responsive control-system operation.

Configuration Breakdown | Decode the AGS813-S10 Order Code

Code Element	Meaning
AGS813	Yokogawa isolated servo module for turbomachinery I/O
-S	Standard type
1	Suffix designation: Always 1
0	Basic type
Complete Model	AGS813-S10

Confirm the complete suffix against the installed module and system parts list. Do not infer interchangeability from the AGS813 prefix alone.

Signal Architecture | From Position Feedback to Servo Command

Signal Path	Module Interface	Control Purpose
Actuator position	4 isolated LVDT inputs	Measure position feedback from compatible transducers
Standardized feedback	4 isolated 1–5 V inputs	Receive voltage-based position signals
Servo command	2 isolated current outputs	Provide adjustable current commands to compatible servo interfaces
Quick-close command	2 isolated digital inputs	Receive 24 VDC ON/OFF signals

Engineering distinction: The module provides signal interfaces. The turbine control application determines how feedback, servo commands, and quick-close logic interact.

Technical Specifications | Electrical and Control Performance

Manufacturer	Yokogawa
Model	AGS813-S10
Product Type	Isolated Turbomachinery Servo I/O Module
Module Function	LVDT feedback, voltage feedback, servo current output, and digital input
Scan Cycle	5 ms
Weight	Approximately 0.36 kg
External Connection	Dedicated cable: AKB337-M005, M007, or M010
Power Consumption	Maximum 500 mA at 5 VDC

Feedback Inputs | LVDT and Standard Voltage

1. LVDT position feedback

Input Channels	4 isolated channels
Supported Wiring	3-wire, 5-wire, and 6-wire configurations
Excitation Voltage	5 Vrms at 30 mArms
Maximum Excitation Current	30 mArms
Excitation Frequency	2.8, 3.0, or 3.2 kHz; independently selectable
Accuracy	±1%; input 0.7–5 Vrms, minimum span 2.5 Vrms
Temperature Drift	±0.4% per 10°C ambient change
Input Impedance	220 kΩ powered; 100 kΩ unpowered
Allowable Input	±30 V peak
External Supply	+11.4 to +13.2 V, 0.3 A
Filtering	Collective filtering

2. Standardized voltage feedback

Input Channels	4 isolated channels
Input Signal	1–5 VDC
Accuracy	±4 mV
Temperature Drift	±4 mV per 10°C ambient change
Input Impedance	1 MΩ powered; 100 kΩ unpowered
Maximum Allowable Input	30 VDC
Filtering	Collective filtering

Servo Outputs | Current Command and Dither

Output Channels	2 isolated channels
Selectable Output Range	±25 mA or ±50 mA, independently selectable
Accuracy	±150 μA at ±25 mA; ±300 μA at ±50 mA
Temperature Drift	±50 μA or ±100 μA per 10°C, respectively
Allowable Load	270 Ω at ±25 mA; 100 Ω at ±50 mA
Open-Circuit Detection	Available
External Supply	+11.4 to +13.2 V, 0.3 A
Dither	0 to ±20% of range at 33 Hz

Match the output range to the servo device's input specification. Verify load resistance and cable characteristics before enabling control.

Digital Inputs | Quick-Close Interface

Input Channels	2 isolated channels
Rated Signal	24 VDC, sink input
ON Voltage	18–26.4 VDC
OFF Voltage	5 VDC or less
Input Current	4.1 mA ±20%
Maximum Allowable Voltage	30 VDC

Verify the field circuit's polarity and voltage thresholds. Confirm quick-close behavior through the approved turbine safety and control procedures.

Isolation and Electrical Withstand

• System-to-field withstand: 500 VAC for one minute.
• Between different input/output types: 500 VAC for one minute.
• Channel isolation: Individual signal groups provide specified isolation.

The stated withstand test does not replace protective grounding or approved wiring separation. Follow the installation manual for field cable routing.

Application Fit | Turbine and Actuator Control

• Gas turbine valve positioning: Reads LVDT feedback and provides servo current commands.
• Steam turbine control: Supports compatible actuator feedback and servo interfaces.
• Fuel control systems: Interfaces with suitable valve-position feedback and control circuits.
• Hydraulic servo systems: Provides current commands to compatible servo devices.
• Quick-close circuits: Receives discrete commands used by the configured control application.
• Turbomachinery control panels: Consolidates feedback and command signals within compatible Yokogawa systems.

These are application categories, not confirmation of compatibility with every turbine model. Check the control-system engineering documentation and actuator specifications.

Installation and Commissioning | Engineering Checklist

1. Verify the complete AGS813-S10 ordering code.
2. Confirm the system rack, slot, and supported hardware revision.
3. Check the dedicated cable part number and required length.
4. Match LVDT wiring to the selected 3-wire, 5-wire, or 6-wire configuration.
5. Set each LVDT excitation frequency according to the transducer specification.
6. Verify the 1–5 V feedback scaling and servo output range.
7. Check external supply voltage and current requirements.
8. Test quick-close input thresholds and application response.
9. Record calibration results and approved control settings.

Use qualified turbine-control personnel. Follow site isolation procedures and the original Yokogawa commissioning instructions.

Diagnostics and Field Maintenance

The module provides circuit-open detection for current outputs. Technicians can also assess feedback signals through system-level monitoring and approved test equipment.

• Servo output open circuit: Investigate wiring continuity, terminal connections, and connected servo input.
• Position feedback mismatch: Compare the LVDT or voltage input with independent position measurements.
• Unstable position reading: Inspect transducer wiring, excitation settings, shielding, and grounding.
• Servo response problem: Check output range, load resistance, command scaling, and actuator condition.
• Quick-close input issue: Measure field voltage and verify ON/OFF thresholds.

Field example: A turbine valve position reading differs from the mechanical indicator. The engineer checks LVDT excitation, wiring configuration, feedback scaling, and actuator linkage. The engineer then validates the servo command and response within the approved test procedure.

Do not treat a feedback discrepancy as proof of module failure. Check the transducer, cabling, mechanical linkage, and configured scaling first.

Compatibility and Selection Guidance

Before selecting this module, verify the complete system configuration. The following information helps prevent ordering and commissioning errors.

• Yokogawa control platform and rack configuration.
• Required AGS813 suffix and hardware revision.
• LVDT type, wiring arrangement, and excitation frequency.
• Voltage-feedback signal range and scaling.
• Servo input range, load resistance, and dither requirements.
• Quick-close circuit voltage and input logic.
• Dedicated cable model and required length.

Confirm approved interchangeability through the system parts list or manufacturer documentation. Similar signal functions do not guarantee direct replacement compatibility.

Environmental and Certification Information

The supplied specifications identify electrical isolation and withstand ratings. They do not provide operating temperature, storage temperature, humidity, vibration, or EMC immunity limits.

Certification details were not supplied for this individual module. Verify the applicable system certification and module documentation before making compliance claims.

Packaging, Shipping, and Warranty

• Product: Yokogawa AGS813-S10 isolated turbomachinery servo module.
• Part identification: AGS813-S10.
• Warranty: 12 months, subject to Global PLC Spare HUB's applicable terms.
• Shipping carriers: FedEx, UPS, and DHL.
• Dispatch target: 24–48 hours after order confirmation, subject to stock and verification.
• Packaging: Protective shipping packaging. Confirm included cables and accessories before ordering.

Global PLC Spare HUB Review | Practical Selection Insight

The AGS813-S10 combines feedback acquisition with servo command generation. Its value lies in matching the electrical interface to the turbine actuator and control configuration.

For an LVDT-based valve, engineers should verify the sensor wiring and excitation frequency before tuning the servo loop. A correct module cannot compensate for incorrect feedback scaling or mechanical linkage problems.

When planning a replacement, record the original suffix, cable code, output range, and feedback type. These details help reduce commissioning delays and avoid incorrect substitutions.

Frequently Asked Questions

1. How do I choose between the ±25 mA and ±50 mA servo output ranges?

Check the servo actuator or amplifier input specification. Select the supported range and confirm its allowable load resistance before connecting the output.

2. Can the module accept different LVDT excitation frequencies across its channels?

Yes. The listed excitation frequencies are independently selectable. Match each channel's setting to its connected transducer requirements.

3. What should I verify when an LVDT replacement produces a different position reading?

Compare wiring, excitation frequency, transducer range, polarity, and configured scaling. Also inspect the mechanical linkage and verify the reading against an approved reference.

4. Does the 5 ms scan cycle determine the complete turbine control response time?

No. The scan cycle describes module timing. Total response also depends on controller execution, application logic, actuator dynamics, and signal processing.

5. What information should accompany a quotation request for this servo module?

Provide the full model code, control-system platform, rack details, feedback type, servo range, and cable requirement. Include the existing module label when available.
