Schneider Electric STBDDI3230 Advantys STB Digital Input Module
Manufacturer: Schneider Electric
Product No.: STBDDI3230
Condition： In stock
Product Type: Digital Input Module
Product Origin: FR
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
Engineers deploy the STBDDI3230 within the Advantys STB series by Schneider Electric.
This STBDDI3230 unit captures discrete field signals efficiently.
Industrial plants integrate this Advantys STB module into distributed I/O architectures.
Global PLC Spare HUB's Insight: Field engineers rely on the STBDDI3230 because its compact modular form factor optimizes cabinet space during brownfield retrofits.
Technical Specifications
| Brand | Schneider Electric |
| Model | STBDDI3230 |
| Series | Advantys STB |
| Module Type | Standard digital input module |
| Channels | 2 channels (sink) |
| Signal Type | 24V DC, IEC/EN 61131-2 Type 2 |
| Isolation | 1500V DC field-to-bus for 1 minute |
| Supply Voltage | 24V DC via PDM |
| Bus Current | 60 mA at 5V DC |
| Measurement Range | 0V DC to 30V DC discrete voltage levels |
| Frequency Response | Up to 500 Hz input switching frequency |
| Sensitivity | IEC Type 2 switching thresholds active |
| Linearity | High linearity digital state detection |
| Resolution | Discrete 1-bit per channel status |
| Temperature Range | Standard industrial enclosure limits apply |
| Environmental Tolerance | IP20 protection rating |
| Interference Immunity | Meets heavy industrial EMC standards |
| Physical Weight | 0.110 kg |
Installation Guide
- Mount the STBDDI3230 onto the STBXBA1000 13.9 mm I/O base.
- Ensure proper connection to the STBPDT3100 PDM for power distribution.
- Verify bus current availability before rack expansion.
- Secure terminal block wiring tightly to prevent intermittent contact.
Commissioning and Maintenance Convenience
- Hot swapping support allows replacement without system shutdown.
- LED indicators provide clear visual channel status feedback.
- Modular design speeds up loop checks during initial startup.
- Quick-release latch mechanisms simplify physical unit extraction.
Compatibility Information
- Compatible with Advantys STB island communication modules.
- Requires STBXBA1000 base and STBPDT3100 PDM components.
- Integrates seamlessly with standard PLC backplane configurations.
Certification Information
- Complies with IEC/EN 61131-2 Type 2 standards.
- CE marked for industrial automation compliance.
- Built to meet stringent international quality benchmarks.
Packing List and Warranty
- One STBDDI3230 digital input module.
- Standard protective packaging unit.
- Comprehensive 12-month warranty terms included.
Shipping and Logistics
- Courier partners: FedEx, UPS, and DHL.
- Fast dispatch within 24 to 48 hours globally.
- Secure tracking provided upon order confirmation.
Typical Application Scenarios
- Discrete sensor monitoring on automated assembly lines.
- Conveyor belt limit switch signal acquisition.
- Packaging machinery status verification.
- Process valve position feedback tracking.
Diagnostic Capabilities
- Channel status LEDs indicate active input states instantly.
- Internal bus communication monitoring detects node drops.
- Field power loss alerts via PDM diagnostics.
Buying Guide
- Verify your existing backplane uses the STBXBA1000 base.
- Confirm channel count requirements match your sensor topology.
- Check current consumption to safeguard your power distribution module.
