IS200TDBTH6ACD GE Mark VIe Terminal Board | 24-Channel Discrete I/O Module
Manufacturer: GE
Product No.: IS200TDBTH6ACD
Condition： In stock
Product Type: Terminal Board
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Advanced Signal Integration: GE IS200TDBTH6ACD
The IS200TDBTH6ACD is a high-performance Discrete Input/Output (TDBT) terminal board, precision-engineered for the GE Mark VIe distributed control architecture. This module provides a robust interface for 24 group-isolated contact inputs and 12 Form-C relay outputs, ensuring seamless communication between field devices and your controller.
Technical Specifications
- Model: IS200TDBTH6ACD
- Series: Mark VIe
- I/O Capacity: 24 discrete inputs, 12 relay outputs.
- Voltage Compatibility: Supports 24V, 48V, or 125V DC wetting voltages.
- Filtering: Integrated hardware filter for noise suppression and surge protection.
- Mounting: DIN-rail or flat surface cabinet mounting.
- Protection: Polymer PTC resettable fuses for 24V DC supply limiting.
Global PLC Spare HUB's Insight
In our technical evaluation at Global PLC Spare HUB, the IS200TDBTH6ACD is recognized for its exceptional TMR (Triple Modular Redundant) support. We recommend this board specifically for critical turbine control applications where high-frequency noise rejection is non-negotiable. Its ability to interface with PDIO I/O packs ensures that your control network remains synchronized across redundant controller pairs.
Applications & Diagnostics
- Applications: Gas turbine control, power generation logic, and industrial safety shutdown systems.
- Diagnostic Capability: Onboard LED indicators and Ethernet-based communication through connected PDIO packs allow for real-time status monitoring of input circuits and relay health.
- Surge Resilience: Designed to withstand harsh industrial electrical environments via built-in MOVs and high-frequency noise filtering.
Logistics & Support
- Rapid Transit: Guaranteed dispatch within 24-48 hours using FedEx, UPS, or DHL.
- Quality Guarantee: Full 12-month warranty included for peace of mind.
- Expert Assistance: Contact our team for integration guidance regarding the Mark VIe I/O configuration (Manual GEH-6721L).
Professional FAQ
Can the IS200TDBTH6ACD function standalone without a PDIO pack?
No, this terminal board requires connection to PDIO I/O packs to communicate with the control system; it cannot operate as an independent controller.
How should I configure the relay outputs for dry contact applications?
If you require dry contacts without external power distribution, simply remove the specific jumpers on the optional WROBH1 relay board.
What is the primary indicator of an input circuit fault?
Monitor the input current draw. Circuits 1-21 are limited to 2.5mA, while 22-24 are limited to 10mA; any deviation indicates a potential ground fault or sensor failure.
Selection Guide: How do I choose the correct wetting voltage for my application?
Select your wetting voltage based on your site's standard DC supply; the board is scaled automatically for 24V, 48V, or 125V environments. Ensure the input threshold matches your sensor specs.
Is the conformal coating critical for my installation?
Yes, the chemically-applied conformal coating is essential for long-term reliability in environments with high humidity or airborne contaminants, preventing trace corrosion.
