CEV65M-00444 TR Electronic 12-Pin M23 Radial SSI Absolute Encoder

Product Overview

• The TR Electronic CEV65M-00444 is a high-performance multi-turn absolute encoder.
• It belongs to the versatile CEV65M series, known for modular mechanical flexibility.
• This unit utilizes the SSI (Synchronous Serial Interface) for high-speed data transmission.
• It features a programmable design, allowing for customer-specific industrial solutions.
• The CEV65M-00444 ensures precision with a Gray code output to prevent data errors.

Technical Specifications

• Brand: TR Electronic
• Model: CEV65M-00444
• Series: CEV65M Multi-turn
• Resolution: 4,096,000 steps per revolution
• Measurement Range: 4,096,000 revolutions (31-bit total resolution)
• Interface: SSI (Synchronous Serial Interface)
• Output Code: Gray Code
• Output Level: RS422
• Supply Voltage: 11-27V DC (24V Nominal)
• Current Consumption: 80 mA (unloaded)
• Temperature Range: 0 to +60°C
• Environmental Protection: Class IP65
• Shock Resistance: 1000 m/s² (11 ms half-sine)
• Vibration Resistance: 100 m/s² (50-2000 Hz)
• Shaft Type: 10mm Shaft with Flat (10FL/19,5)
• Connector Type: 12-pin M23 Radial Connector

Installation and Compatibility

• Mount the CEV65M-00444 using the ZB36 standard flange for secure alignment.
• Connect the device using the 185E pinout configuration for proper signal routing.
• The CEV65M series is compatible with Siemens, Allen-Bradley, and Mitsubishi SSI modules.
• Ensure the M23 connector is fully seated to maintain the IP65 moisture protection.
• Use TRWinProg software for field parametrization and resolution adjustments.

Diagnostics and Maintenance

• Monitor integrated error signals to detect internal hardware or signal transmission faults.
• Use the movement status signal for real-time verification of rotational activity.
• The CEV65M-00444 features programmable limit switches for advanced position monitoring.
• Regularly inspect the 10mm shaft and coupling for signs of mechanical wear.
• Maintenance is minimal due to the high-end bearing life of 3.9E+10 revolutions.

Typical Application Scenarios

• High-precision positioning in CNC machining centers and metalworking equipment.
• Feedback control for industrial robotic arms and automated assembly lines.
• Synchronized motion control in packaging machinery and conveyor systems.
• Wind turbine pitch control and heavy-duty crane positioning systems.

Global PLC Spare HUB's Insight

• The CEV65M-00444 offers exceptional reliability in electrically noisy environments via RS422.
• Engineering teams prefer the CEV65M series for its modularity and ease of integration.
• This encoder provides a stable 31-bit total resolution suitable for complex long-travel tasks.

Shipping and Warranty

• Shipping Time: Dispatched within 24-48 hours.
• Logistics Partners: Express delivery via FedEx, UPS, and DHL.
• Package List: 1 x CEV65M-00444 Encoder, 1 x Mating Plug.
• Warranty: Includes a comprehensive 12-month quality guarantee.

Selection Guide & FAQ

• How do I choose between different CEV65M models?
• Always match the shaft diameter (10mm for this model) and the interface type (SSI).
• What is the benefit of Gray Code in the CEV65M-00444?
• Gray Code ensures only one bit changes at a time, preventing reading errors.
• Does this unit support external preset adjustment?
• Yes, it includes electronic preset inputs for zeroing the position remotely.
• Can I use this in wash-down environments?
• The IP65 rating protects against water jets, making it suitable for damp areas.
