TM2DMM24DRF Schneider Electric Modicon M238 Mixed I/O Expansion Module
Manufacturer: Schneider Electric
Product No.: TM2DMM24DRF
Condition： In stock
Product Type: Mixed I/O Expansion Module
Product Origin: FR
Payment: T/T, Western Union
Weight: 350g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview & Global PLC Spare HUB Review
The Schneider Electric TM2DMM24DRF functions as a high-density mixed input-output expansion module tailored for the Modicon M238 Series. Featuring 16 discrete DC inputs and 8 reliable relay outputs, this expansion unit seamlessly extends controller capability for complex machine architectures. Global PLC Spare HUB Review emphasizes that utilizing modular I/O expansions allows automation engineers to scale up control loops efficiently without replacing main controller racks, optimizing both cabinet space and capital expenditure.
Technical Specifications
| Technical Parameter | Specification Detail |
|---|---|
| Manufacturer & Series | Schneider Electric / Modicon M238 Series |
| Model Number | TM2DMM24DRF |
| Discrete Inputs | 16 digital inputs operating at 24 V DC (sink or source logic) |
| Relay Outputs | 8 digital relay outputs with 2 A maximum current per channel |
| Input Impedance | 3.4 kOhm resistance for precise signal acquisition |
| Electrical Durability | Rated for 100,000 cycles under standard inductive and resistive loads |
| Mounting & Dimensions | Mounts on standard 35 mm symmetric DIN rail; dimensions 90 x 42.9 x 70 mm |
Equipment Compatibility & Industrial Applications
This expansion module is fully compatible with Modicon M238 logic controllers as well as legacy Advantys OTB and Twido architectures. Industrial control builders integrate the TM2DMM24DRF into automated packaging lines, material handling conveyors, textile machinery, and water treatment skids where mixed digital control signals are required.
Diagnostic Capabilities
Equipped with an integrated local display block, the module allows technicians to instantly verify channel statuses, monitor active input/output switching, and quickly isolate wiring faults during commissioning or routine preventive maintenance without needing external diagnostic tools.
