TM258LF42DT4L Schneider Electric Modicon M258 Compact Logic Controller
Manufacturer: Schneider Electric
Product No.: TM258LF42DT4L
Condition： In stock
Product Type: Logic Controller
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Engineering Overview
The **TM258LF42DT4L** is a high-performance compact logic controller engineered by **Schneider Electric** within the **Modicon M258** series. Powered by a dual-core ARM Cortex-A8 processor, it separates execution and communication tasks to guarantee maximum processing speed and deterministic control in multi-axis automation architectures.
Technical Architecture & System Specifications
| Manufacturer & Series | **Schneider Electric** **Modicon M258** |
| Model Designation | **TM258LF42DT4L** |
| Processor Architecture | Dual-core ARM Cortex-A8 (Core 1: logic execution, Core 2: comms) |
| Memory Capacity | 128 K instructions program memory; 64 MB RAM and 128 MB Flash data memory |
| Execution Speed | 0.022 µs per Boolean instruction (over 45,000 instructions per ms) |
| Embedded I/O Layout | 42 total points (26 digital inputs including 8 high-speed counters, 16 transistor outputs, 4 analog inputs) |
| Expansion Limits | Supports up to 7 TM5/TM2 expansion modules (max 2400 total I/O) plus 2 optional PCI communication slots |
| Electrical Supply | 24 V DC nominal (19.2 to 28.8 V range), 14.14 W consumption |
| Physical Dimensions | 99 mm × 265 mm × 75 mm; 0.77 kg weight; IP20 protection rating |
Global PLC Spare HUB Insight & Engineering Strategy
Global PLC Spare HUB specialists note that the dual-core architecture of the **TM258LF42DT4L** makes it ideal for complex motion coordination where communication traffic must not impede real-time task scanning. When configuring expansion racks, ensure that bus power limitations across TM5 modules are carefully calculated to prevent voltage drop over heavy distributed arrays.
Target Equipment & Application Capabilities
OEM machine builders deploy this controller on high-speed packaging machinery, automated assembly lines, material handling sorting systems, and multi-axis CNC routers. Its onboard high-speed counters (100 kHz) and analog channels provide advanced diagnostic capabilities, real-time axis tracking, and closed-loop process regulation.
Logistics, Warranty & Express Fulfillment
- Global Courier Network: Secure and swift dispatch via FedEx, UPS, and DHL.
- Fulfillment Schedule: Rapid order processing and shipping within 24 to 48 hours.
- Warranty Assurance: Fully protected by a comprehensive 12-month industrial replacement warranty.
- Packaging Standards: Anti-static factory packaging designed to prevent transit damage.
Frequently Asked Questions
Q: What programming environments are compatible with the **TM258LF42DT4L** controller?
A: It is programmed using SoMachine or EcoStruxure Machine Expert software suites.
Q: How do the dual cores divide system tasks?
A: Core 1 handles deterministic program logic tasks while Core 2 manages communication overhead independently.
Q: Can users expand communication capabilities beyond built-in ports?
A: Yes, the unit includes two free PCI slots specifically for optional communication and function modules.
Q: What is the selection criterion for utilizing the high-speed counter inputs?
A: The 8 fast HSC inputs support up to 100 kHz, making them perfect for direct encoder feedback from high-speed servo motors.
Q: How should engineers handle thermal management in tight control cabinets?
A: Maintain an ambient operating range between 0°C and 55°C (up to 60°C with derating) and ensure adequate airflow around the IP20 housing.
