MC07B0040-5A3-4-00 SEW MOVITRAC B Frequency Inverter | 4kW 3-Phase

Product Overview

The MC07B0040-5A3-4-00 is an advanced 3-phase frequency inverter engineered by SEW-Eurodrive under the popular MOVITRAC® B series. Designed to deliver precise motor speed regulation, the MC07B0040-5A3-4-00 handles a 4.0 kW (5.4 HP) motor load with a rated output current of AC 9.5 A. Built-in features like a C2 radio interference suppression filter, an integrated brake chopper for four-quadrant (4Q) operation, and modular expansion slots for DFE32B Profinet and FSC11B communication cards make this drive ideal for demanding industrial motion control loops.

Technical & Environmental Specifications

• Brand / Manufacturer: SEW-Eurodrive
• Product Series: MOVITRAC® B
• Model Number: MC07B0040-5A3-4-00
• Device Type: Frequency Inverter / AC Drive
• Power Supply Connection: 380–500 VAC, 3-phase, 50/60 Hz
• Motor Power Rating: 4.0 kW / 5.4 HP (3.0 HP nominal mapping)
• Rated Output Current: AC 9.5 A
• Hardware Size: Size 0L
• Physical Weight: 2.1 kg / 4.6 lb
• Braking Capability: Integrated 4-quadrant operation with built-in brake chopper
• EMC Filter Rating: C2 suppression level
• Expansion Slots: Compatible with DFE32B Profinet and FSC11B communication modules

Installation & Wiring Guidelines

• Mount the MC07B0040-5A3-4-00 vertically inside a clean, well-ventilated electrical control cabinet to ensure optimal thermal dissipation for Size 0L hardware.
• Connect incoming 3-phase 380-500V AC power lines securely to the designated input terminals while maintaining proper earth grounding.
• Wire the motor leads using shielded cables to comply with C2 electromagnetic compatibility and radio suppression standards.
• Install optional communication cards (such as the DFE32B or FSC11B) into the dedicated front expansion bays prior to initial power-up.

Diagnostics & Monitoring Capabilities

• Track operational faults, speed references, and DC-link voltage status using the built-in 7-segment LED display and diagnostic keypad interface.
• Monitor internal temperature and motor overload states via internal microprocessor trip diagnostics.
• Utilize fieldbus diagnostic LEDs on attached communication options to troubleshoot network packet exchange and Profinet link integrity in real time.

Target Equipment & Application Scenarios

• Automated conveyor belts and material handling systems requiring dynamic speed control.
• Industrial pumps, fans, and centrifugal blowers requiring energy-efficient variable frequency operation.
• Packaging machinery and automated assembly lines needing fast 4-quadrant braking response.
• Material handling cranes and hoist mechanisms utilizing integrated brake chopper control.

Ordering, Shipping, and Warranty Terms

• Stock Availability: In-stock inventory ready for immediate dispatch.
• Processing Window: Fast 24-48 hour order handling.
• Logistics Carriers: Secure global shipping via FedEx, UPS, and DHL.
• Warranty Protection: Comprehensive 12-month warranty included with every MC07B0040-5A3-4-00 unit.

Global PLC Spare HUB's Insight

When commissioning or replacing variable frequency drives in heavy industrial environments, sudden overvoltage trips during deceleration are a frequent hazard. Based on field expertise at Global PLC Spare HUB, technicians deploying the MC07B0040-5A3-4-00 should correctly size and wire an external braking resistor to the built-in brake chopper terminals if the application involves high-inertia loads. This prevents DC-link overvoltage faults and protects the inverter's power transistors from thermal stress during rapid 4-quadrant braking cycles.

Frequently Asked Questions

What is the primary purpose of the integrated brake chopper on the MC07B0040-5A3-4-00?

The built-in brake chopper allows the inverter to handle regenerative energy during rapid motor deceleration by shunting excess DC-link voltage to an external braking resistor.

Can expansion communication cards be added to this MOVITRAC B inverter?

Yes, the drive supports modular fieldbus integration, allowing technicians to install options like the DFE32B Profinet card or FSC11B communication module.

What shopping and selection criteria should engineers follow when purchasing this drive?

Verify that your incoming supply voltage matches the 380-500V 3-phase rating, confirm that the 4 kW output capacity suits your motor specifications, and purchase exclusively from certified suppliers offering a 12-month warranty.

What immediate troubleshooting step should be taken if an overcurrent fault code appears on the display?

Disconnect the motor load to test the inverter baseline, inspect motor power cables for short circuits or ground faults, and verify that ramp-up times are not set too aggressively.

How does the C2 suppression filter benefit industrial control panels?

The integrated C2 filter limits electromagnetic radio frequency interference, helping the installation comply with stringent industrial EMC emission standards.
