Honeywell 900U01-0100 Universal I/O Module | 16-Channel HART
Manufacturer: Honeywell
Product No.: 900U01-0100
Condition： In stock
Product Type: I/O Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 250g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The 900U01-0100 Universal I/O Module represents the next generation in flexible process control. Engineers can soft-configure each of the 16 channels as Analog Input (AI), Analog Output (AO), Digital Input (DI), or Digital Output (DO). This high-density module supports HART communication, enabling seamless integration with intelligent field devices. It reduces hardware inventory costs by consolidating multiple signal types into a single, reliable unit.
Global PLC Spare HUB Insight
The 900U01-0100 is a premier choice for distributed control systems (DCS). It excels in environments requiring rapid reconfiguration without physical wiring changes. Reliability, high galvanic isolation, and precision make it essential for process industries. It is fully compatible with Honeywell ControlEdge PLC and HC900 controller systems, ensuring seamless automation upgrades.
Technical Specifications
- Module Type: Universal I/O Module, 16-Channel
- Measurement Range (AI): 0-20 mA or 4-20 mA with HART support
- Output Range (AO): 0-23 mA
- Resolution: 16-bit (AI); 12-bit (AO)
- Linearity: Output current linearity < 0.05%
- Frequency Response: First-order low-pass filter at 100Hz
- Accuracy: 0.1% of full-scale (23.5 ± 2°C); 0.25% (0 to 60°C)
- Temperature Range: 0°C to +60°C
- Environmental Tolerance: Galvanic isolation of 1kV AC
- Interference Rejection: Crosstalk attenuation of 58dB (DC to 60 Hz)
- Diagnostics: Supports open wire, lead breakage, and short-circuit detection
Installation and Maintenance
- Ensure field devices connect within the 24V DC supply limits (22V-27V).
- Mount the module firmly to the rack for effective signal isolation.
- Software-driven configuration simplifies commissioning and maintenance tasks.
- Disable line monitoring for digital outputs driving loads below 10mA.
- On-module diagnostic LEDs provide real-time status for quick troubleshooting.
Compatibility and Standards
- Compatibility: Designed for ControlEdge PLC and compatible process automation racks.
- HART Support: Fully compatible with HART 7 protocol for smart device management.
- Certification: Built to meet rigorous industrial safety and quality standards.
Logistics and Support
- Packaging: Secure industrial-grade packaging ensuring transit safety.
- Warranty: Full 12-month quality assurance warranty included.
- Shipping: Global delivery via FedEx, UPS, and DHL.
- Lead Time: Orders process and ship within 24-48 hours.
Purchasing Guide
- Channel Mapping: Calculate total power; max load is 4.2A per module.
- Load Requirements: If AO load exceeds 100 ohms, verify channel count in the user manual.
- System Integration: Confirm controller firmware supports the 900U01-0100 profile.
Frequently Asked Questions
Can I mix AI and DO on the same 900U01-0100 module?
Yes, each of the 16 channels is independently software-configurable.
Why am I receiving nuisance alarms on my Digital Output?
This occurs when the load current is less than 10mA. We recommend disabling Line Monitoring for those channels.
What is the benefit of HART support in this module?
HART support allows remote device diagnostics and configuration, improving predictive maintenance.
How do I handle maintenance for this module?
Disconnect field power, remove the terminal block, and slide the module out of the rack for easy replacement.
