GE Mark VI IS200STTCH2AAA Thermocouple Terminal Board
Manufacturer: GE
Product No.: IS200STTCH2AAA
Condition： In stock
Product Type: Thermocouple Terminal Board
Product Origin: GE
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The IS200STTCH2AAA is a high-performance thermocouple terminal board engineered for the GE Mark VI control system. This module serves as a critical interface for thermocouple sensor inputs, ensuring precise signal acquisition. You can deploy this board in either simplex or triple redundant system configurations. The design prioritizes signal integrity through integrated noise suppression components. It provides a robust, DIN-rail mounted solution for demanding industrial environments.
Technical Specifications
- Manufacturer: General Electric (GE)
- Product Series: Mark VI
- Model Number: IS200STTCH2AAA
- Component Type: DIN Rail Thermocouple Terminal Board
- Signal Interface: 48-position terminal strip (two rows of 24)
- System Connector: 37-position female DC connector
- Noise Immunity: Integrated high-frequency ferrite beads, resistors, and capacitors
- Mounting Standard: DIN rail support with chassis ground capability
- Temperature Range: Designed for standard industrial control cabinet conditions
Installation, Maintenance, and Compatibility
- Installation: Snap the unit onto standard DIN rails for secure mechanical support. Ensure proper chassis grounding to the rail for optimal shielding.
- Maintenance: The modular layout allows for rapid wire termination via screw terminals. Visual inspection of the integrated circuit (U1) and passive components is straightforward.
- Compatibility: Fully compatible with Mark VI I/O packs and associated turbine control hardware.
- Diagnostic Capability: The board’s passive circuitry facilitates clean signal path validation, simplifying loop-check procedures.
Shipping and Warranty
- Shipping Carriers: We utilize FedEx, UPS, and DHL for secure global transport.
- Lead Time: Orders process and ship within 24–48 hours.
- Warranty: This product includes a comprehensive 12-month quality assurance warranty.
- Package Contents: Includes the IS200STTCH2AAA module, documentation reference, and protective industrial packaging.
Typical Application Scenarios
This terminal board integrates into heavy-duty gas and steam turbine control systems. It is primarily used in power generation, petrochemical processing, and oil and gas infrastructure where thermocouple temperature sensing requires high reliability.
Global PLC Spare HUB's Insight
The IS200STTCH2AAA represents the gold standard for signal termination in GE Mark VI architecture. Our technical team identifies this board as a mission-critical link between raw thermal sensors and the main controller. It is ideal for facilities requiring long-term stability and effective noise suppression in high-EMI environments.
Frequently Asked Questions
Can the IS200STTCH2AAA handle mixed thermocouple types?
Yes, the terminal board serves as a physical passthrough. You must ensure your corresponding I/O pack is configured for the specific thermocouple type.
What is the advantage of the ferrite bead design?
The ferrite beads effectively filter high-frequency noise from your process signals. This reduces the risk of temperature reading fluctuations in electrically noisy turbine halls.
Is this board suitable for critical safety loops?
Yes, it is designed for use in both simplex and triple modular redundant (TMR) systems, meeting high-availability requirements.
How do I choose the correct version for my system?
Verify your current Mark VI rack configuration and the existing terminal board part number. The IS200STTCH2AAA is a direct replacement for specified thermocouple termination tasks.
What should I check if I see signal drifting?
Check all 48 terminal screw connections for oxidation or looseness. Also, inspect the ribbon cable connector for proper seating and pin alignment.
