GE Mark IV DS3800XTFP1E1C Thyristor Fan Out Board | Turbine Control
Manufacturer: GE
Product No.: DS3800XTFP1E1C
Condition： In stock
Product Type: Thyristor Fan Out Board
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The DS3800XTFP1E1C functions as a critical Thyristor Fan Out Board within the General Electric Mark IV Speedtronic turbine control architecture. This module provides essential signal isolation and distribution, ensuring high-power thyristors receive accurate control inputs for turbine speed and load regulation.
Technical Specifications
- Manufacturer: General Electric (GE)
- Series: Mark IV Speedtronic
- Part Number: DS3800XTFP1E1C
- Product Type: Thyristor Fan Out Board
- Input Signal Range: 4-20 mA / 0-10 V DC
- Output Signal Range: 0-10 V DC
- Output Channels: 6 to 12 configurable outputs
- Power Supply: 110-240 V AC / 24 V DC
- Operating Temperature: -30°C to 55°C
- Dimensions: 8.25 cm height x 4.18 cm width
- Environmental Tolerance: Conformal coating for vibration and humidity resistance
Functional Capabilities
- Signal Distribution: The module splits centralized control signals into multiple discrete output channels to drive individual thyristor gates synchronously.
- Power Regulation: It facilitates precise control of electrical energy flow to turbine motor and generator systems.
- Synchronization: The architecture maintains strict timing protocols, preventing phase misalignment in high-power switching.
- Overcurrent Protection: Hardware-level design prevents excessive electrical flow, protecting downstream components.
- Diagnostic Ability: The logic gate interface allows for rapid status verification and effective troubleshooting during downtime.
Installation and Maintenance
- Mounting: Utilize the four pre-drilled corner holes and two bottom-edge holes to secure the board.
- Connectivity: Ensure the male terminal port is securely mated to the host backplane to avoid signal jitter.
- Maintenance: Regularly inspect the board for dust accumulation or terminal corrosion.
- Compatibility: Designed exclusively for the Mark IV series architecture.
Logistics and Support
- Warranty: This component includes a 12-month quality assurance warranty.
- Packaging: Secure anti-static industrial packaging ensures component integrity during transit.
- Shipping: Expedited shipping available via FedEx, UPS, and DHL.
- Lead Time: Orders are processed and dispatched within 24-48 hours.
Typical Application Scenarios
- Gas turbine ignition and fuel control systems.
- Steam turbine power distribution and load management.
- High-power industrial electrical motor synchronization.
Frequently Asked Questions (FAQ)
What is the primary indicator of a faulty fan out board?
Common indicators include inconsistent output signals, erratic turbine speed fluctuations, or repeated overcurrent protection trips.
Can I use the DS3800XTFP1E1C in a non-Mark IV system?
No. This module is specifically engineered for the Mark IV series and is not compatible with other platforms.
How should I handle signal noise interference?
Ensure all ground paths are clean and that signal cabling is properly shielded and routed away from high-voltage AC lines.
Global PLC Spare HUB's Insight
As industry experts at Global PLC Spare HUB, we observe that the DS3800XTFP1E1C remains a cornerstone for legacy Mark IV deployments. Its reliability in high-heat and high-vibration environments makes it essential for maintaining the operational longevity of aging turbine assets. We recommend maintaining a localized spare inventory of this board to minimize emergency downtime.
