BMXFTB2010 20-Pin Screw Clamp Terminal Block for Modicon X80 Series
Manufacturer: Schneider Electric
Product No.: BMXFTB2010
Condition： In stock
Product Type: Terminal Block
Product Origin: FR
Payment: T/T, Western Union
Weight: 93g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Connectivity Architecture & Specifications
The BMXFTB2010 is a precision-engineered 20-pin removable screw clamp terminal block designed for the Modicon X80 automation platform. It serves as the primary interface for field wiring, providing robust signal integrity for high-density I/O modules. Its modular architecture simplifies maintenance, allowing for rapid replacement of I/O hardware without disrupting individual field wire terminations.
Technical Parameters
- Brand: Schneider Electric
- Model: BMXFTB2010
- Series: Modicon X80
- Interface Type: 20-Pin Removable Screw Clamp
- Wire Capacity: 1 or 2 conductors, 0.34 to 1.5 mm² (22-16 AWG)
- Net Weight: 0.075 kg
- Compliance: EU RoHS Pro-active, Toxic/Mercury free
Installation & Operational Reliability
- Wiring Efficiency: Secure individual conductors via the high-torque screw clamp interface.
- Maintenance: The removable design facilitates hot-swapping during scheduled downtime, reducing MTTR (Mean Time To Repair).
- Compatibility: Perfectly matched for any Modicon X80 module requiring a 20-pin interface configuration.
Global PLC Spare HUB's Insight
Engineers often overlook the terminal block, but the BMXFTB2010 is critical for maintaining signal path stability. Our field diagnostics suggest that ensuring proper torque on the screw clamps during initial installation significantly prevents intermittent I/O faults caused by vibrations. This component is an essential safeguard for keeping your X80 control system running at peak performance.
Professional FAQ
Q: Can I use 2.5 mm² wire with this terminal block?
A: No, the BMXFTB2010 is strictly rated for 0.34 mm² to 1.5 mm² conductors; exceeding this range will prevent proper clamp engagement.
Q: Is this block compatible with non-X80 modules?
A: This model is specifically optimized for Modicon X80 series modules requiring a 20-pin interface and should not be cross-applied to incompatible hardware.
Q: What is the benefit of the "removable" feature during troubleshooting?
A: You can disconnect all I/O wiring as a single unit, allowing you to swap a faulty I/O module in seconds without re-terminating any signal wires.
Q: How do I identify a loose connection on this terminal block?
A: Perform a visual inspection for heat discoloration or perform a tug test on each wire to ensure the screw clamp has not backed out due to cabinet thermal cycling.
Q: Are there any special tools required for wiring?
A: A standard flat-blade screwdriver is sufficient, though we recommend a torque-calibrated driver to ensure all 20 terminals meet manufacturer standards.
Logistics & Quality Assurance
- Expedited Shipping: Orders are processed and dispatched within 24-48 hours via FedEx, UPS, or DHL.
- Warranty Policy: Each BMXFTB2010 is covered by a 12-month quality assurance guarantee.
- Packaging: Secure, industrial-grade packaging protects the terminal pins during transit.
