2789-144 Bently Nevada 3000 Series Extension Cable Sensor Lead

Product Overview

The Bently Nevada 3000 Series 2789-144 is an unarmored transducer extension cable designed for 15-foot proximity sensor systems.

Engineers utilize this precision coaxial lead to route high-frequency signal output from proximity probes to remote Proximitor modules.

The cable features chemical-resistant Tefzel insulation paired with ProxMatch color and alphanumeric coding for accurate system length verification.

Gold-plated brass hex connectors ensure low-resistance contact while preventing impedance mismatch across the 50-ohm signal loop.

Its flexible, unarmored design allows smooth routing through tight conduit runs with a tight 1-inch minimum bend radius.

Configuration Breakdown

The structured list below outlines the complete order code breakdown for model 2789-144.

• Model Base Identifier: 2789 (Extension Cable for 3000 Series Proximity Transducer Systems)
  • Cable Length Code: 144 (144 inches / 12 feet cable length; calibrated for 15-foot total system length)
  • Armor Option: Standard unarmored flexible coaxial cable construction

Technical Architecture & System Parameters

Key technical specifications are organized into distinct functional parameter domains below.

Target Equipment & Application Scenarios

The 3000 Series extension cable supports eddy current signal transmission across critical industrial plant machinery.

• Steam Turbines & Generators: Connects internal rotor shaft clearance probes to external junction boxes.
• Boiler Feed Pumps: Routes radial vibration signals through high-temperature bearing housing pathways.
• Centrifugal Gas Compressors: Transfers axial displacement measurements across oil-lubricated seals.
• Large Electric Motors: Links sleeve bearing monitoring probes to machinery protection panels.

Diagnostic Capabilities & Field Integrity

The 2789-144 cable preserves precise RF signal response to enable accurate machinery diagnostics.

• ProxMatch Verification: Integrated color and alphanumeric coding prevents accidental mixing of different system lengths.
• Connector Contact Integrity: Gold-plated contact surfaces prevent oxidation buildup and intermittent signal noise spikes.
• Impedance Match Stability: Strict 50-ohm cable tolerance prevents high-frequency signal reflections that skew scale factor readings.
• Interference Protection: Tefzel coaxial dielectric maintains high insulation resistance in high-humidity operating environments.

Global PLC Spare HUB's Insight

During a turbine overhaul, field technicians encountered baseline signal drift across legacy 3000 Series vibration loops.

Inspection revealed that mixed non-matched extension cables were installed, throwing off overall system impedance.

The mismatched cable capacitance caused scale factor errors, resulting in false high-vibration alarm triggers.

Replacing the worn lines with genuine 2789-144 cables restored exact 15-foot loop balance instantly.

The ProxMatch color tags allowed fast verification without needing manual electrical length measurement during startup.

Installation & Torque Guidelines

Adhere to these technical handling procedures during field cable connection and routing.

• For hex-to-hex connectors, tighten finger-tight and apply a 1/8-turn with calibrated wrenches.
• For hex-to-click connectors, apply finger-tight tension plus 1/8-turn using a wrench and pliers.
• Do not bend the unarmored cable tighter than the 1.0-inch minimum bend radius to prevent inner coaxial damage.
• Always wrap outdoor or oil-exposed connector joints with protective silicone self-fusing tape.

Procurement, Shipping & 12-Month Warranty

We supply authentic industrial automation spares globally backed by full service guarantees.

• Package Contents: 1 x Bently Nevada 2789-144 unarmored extension cable.
• Warranty Terms: Covered by a comprehensive 12-Month replacement warranty.
• Global Express Courier: Fast international dispatch via FedEx, UPS, or DHL.
• Order Processing Time: Orders ship within 24 to 48 hours following payment confirmation.

Frequently Asked Questions

Q: How do I select the proper extension cable length for my 3000 Series system?

A: Match the cable length code to your total calibrated system requirement, ensuring the combined probe and cable match the driver calibration.

Q: What happens if I connect a 144-inch cable to a system calibrated for a 5-meter total length?

A: Connecting improper cable lengths alters total circuit capacitance, causing incorrect scale factors and inaccurate vibration readings.

Q: How can I verify that the gold-plated connectors are tightened correctly in the field?

A: Tighten connectors finger-tight, then turn an additional 1/8-turn with wrenches to establish 60 lbf tensile hold without stripping threads.

Q: Is this unarmored extension cable suitable for direct exposure to lube oil and moisture?

A: Yes, the Tefzel jacket resists oil and moisture, but the connector joints must be sealed with protective boots or tape.

Q: What delivery options are available for urgent international plant shutdowns?

A: We offer express international shipping via FedEx, UPS, and DHL with order handling completed within 24 to 48 hours.
