1769-IQ32 Compact I/O Series Allen-Bradley 24VDC Digital Input Unit
Manufacturer: Allen-Bradley
Product No.: 1769-IQ32
Condition： In stock
Product Type: Input Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 150g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
High-Density Channel Architecture & Layout
Engineered by Rockwell Automation, the 1769-IQ32 is a high-density digital input module designed for the Compact I/O platform. It packs 32 discrete 24V DC input channels divided into four isolated groups of eight, supporting both sinking and sourcing wiring configurations to match diverse field sensor requirements.
Technical Specifications & Electrical Parameters
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Model / Part Number | 1769-IQ32 |
| Product Family | Compact I/O / CompactLogix |
| Module Type | 32-Point Digital DC Input Module |
| Voltage Rating | 24V DC Sink/Source (10-30V DC Operating) |
| Channel Distribution | 4 Groups of 8 Inputs |
| Input Delay Time | 8 ms Nominal (On-State) |
| Power Supply Distance Rating | 8 Modules Max from Power Source |
| Replacement Terminal Block | 1769-RTBN18 |
Status Diagnostics & Isolation Framework
The unit features comprehensive front-panel LED indicators mapped directly to all 32 channels for real-time status tracking. It utilizes a reinforced insulation circuit providing 75V DC continuous isolation (tested at 1697V DC for 1 second) between input points and the system bus, as well as across the four isolated input groups.
Global PLC Spare HUB Insight & Field Engineering Tips
Global PLC Spare HUB control technicians caution that because this high-density module has a power supply distance rating of 8, positioning it too far from the system power supply without an intervening expansion power supply will cause low-voltage faults. Ensure field cabling uses proper 22-14 AWG copper wire to mitigate signal degradation over extended runs.
Target Equipment & Industrial Applications
The 1769-IQ32 is optimized for machine automation racks tied to CompactLogix controllers and MicroLogix 1500 systems. Typical deployments include high-speed sorting systems, automated assembly lines, packaging machinery, and multi-sensor discrete data acquisition skids.
Logistics, Shipping & Warranty Protection
All items dispatch securely within 24 to 48 hours worldwide. Trusted logistics carriers include FedEx, UPS, and DHL. Every 1769-IQ32 unit arrives backed by our comprehensive 12-month replacement warranty.
Selection Guide & Installation Checklist
Verify that your controller rack configuration leaves an available 1.5-inch slot width and respects the strict 8-module distance limit from the power supply. Ensure your cabinet environment adheres to standard industrial temperature limits between 0°C and 60°C.
Frequently Asked Questions
Q: How are the 32 input channels organized on the 1769-IQ32?
A: They are arranged into four distinct groups of eight inputs, with each group supporting individual sink or source wiring configurations.
Q: Why is the power supply distance rating important for this module?
A: The module must be placed within 8 modules of the system power supply to ensure stable internal bus voltage delivery without voltage drop issues.
Q: What terminal block is compatible with this high-density input unit?
A: It utilizes the replacement terminal block model 1769-RTBN18 for secure field signal termination.
Q: Does this module support both DIN rail and panel mounting methods?
A: Yes, it can be securely installed using either a standard DIN rail or direct panel mounting configuration with specialized terminal screws.
Q: What is the operating input voltage range at standard ambient temperatures?
A: The operating voltage range spans from 10 to 30V DC at 30 °C, dropping slightly to 10 to 26.4V DC at 60 °C.
