GE Fanuc IC695STK003 RX3i Power Package 3 Starter Kit PLC

Product Overview

The IC695STK003 RX3i Power Package 3 Starter Kit delivers an integrated automation solution combining advanced control, motion capabilities, and operator interface hardware. Built for industrial environments, this comprehensive kit features the IC695CPU305 controller, a motion module, and a QuickPanel View 6-inch STD terminal. Engineers leverage this platform to accelerate system prototyping and deployment across discrete and process automation applications.

Technical Specifications

Installation Guide

• Mount the IC695CHS012 backplane securely inside a standard NEMA-rated industrial control enclosure.
• Ground the backplane using low-impedance copper braided wire to minimize electrical noise susceptibility.
• Slide the IC695PSA040 power supply and IC695CPU305 CPU into designated primary slots.
• Insert the IC694DSM314 motion module and IC695ETM001 communication module into available PCI slots.
• Connect the QuickPanel View terminal to the controller network using industrial-grade shielded Ethernet cables.

Debugging and Maintenance Convenience

• Built-in LED diagnostics on the IC695CPU305 provide real-time status indication for run, I/O fault, and memory errors.
• Firmware updates deploy seamlessly over Ethernet using PACMachine Edition software without physical chip replacements.
• Hot-insertion capability for select I/O modules reduces system downtime during scheduled maintenance cycles.
• Modular architecture allows targeted component swapping without rewiring field termination blocks.

Compatibility and Ecosystem

• Fully compatible with PACSystems RX3i backplanes and expansion racks.
• Supports standard industrial communication protocols including Modbus TCP, Profinet, and SRTP.
• Integrates smoothly with third-party drives and sensors via standard analog and digital expansion modules.

Kit Packing List

• One IC695CPU305 CPU module
• One IC695CHS012 12-slot backplane
• One IC695LRE001 loader module
• One IC695PSA040 power supply
• One IC695ETM001 Ethernet interface module
• One IC694DSM314 motion module
• One IC694ACC300 connector kit
• One IC694MDL940 discrete output module
• One IC754VSI06STD QuickPanel View 6" operator interface
• Associated cables and dedicated power supply for the QuickPanel

Warranty and Fulfillment

• Backed by a standard 12-month warranty covering structural and functional manufacturing defects.
• Expedited global shipping available via FedEx, UPS, and DHL.
• Guaranteed dispatch within 24-48 hours from order confirmation.

Typical Application Scenarios

• Packaging machinery requiring synchronized multi-axis motion and local HMI visualization.
• Water treatment plants needing robust programmable logic control with remote Ethernet monitoring.
• Discrete manufacturing assembly lines demanding high-speed data processing and reliable sensor feedback.

Global PLC Spare HUB's Insight and Field Experience

Engineering teams often deploy the IC695STK003 starter kit during initial machine prototyping to validate motion profiles before scaling to full production racks. Field experience shows that maintaining dedicated shielding on the IC694DSM314 motion module cabling completely eliminates high-frequency electrical noise interference from nearby variable frequency drives. When replacing legacy Series 90-30 systems, engineers should verify backplane power budget calculations carefully to ensure the IC695PSA040 supplies adequate current for expanded option modules.

Frequently Asked Questions

Q: Can the motion module included in the IC695STK003 kit drive servo motors directly?
A: The kit includes the IC694DSM314 motion module, but compatible servo drives and amplifiers must be purchased separately.

Q: What programming software is required to configure the IC695CPU305 controller?
A: Configuration requires Emerson Machine Edition software communicating via Ethernet or serial connection ports.

Q: How do I handle firmware upgrades for the QuickPanel View terminal?
A: Firmware updates transfer via USB or Ethernet interface using update utility packages provided by the manufacturer.

Q: What precautions prevent communication dropouts on the IC695ETM001 module?
A: Always use industrial-grade shielded CAT5e cables and route communication lines away from high-voltage motor power cables.
