148239-01-18-50-02 Bently Nevada 3300 XL 11mm Underwater Proximity Probe
Manufacturer: Bently Nevada
Product No.: 148239-01-18-50-02
Condition： In stock
Product Type: Proximity Probe
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Engineering Insight & Performance Summary
The 148239-01-18-50-02 is a specialized 3300 XL 11mm Underwater Proximity Probe engineered by Bently Nevada for submerged machinery applications. Featuring a 304 stainless steel sealed case protected by attached Tefzel tubing, this probe reliably measures radial vibration and position when exposed to sub-surface process fluids. It operates in environments ranging from -51°C to +177°C and withstands differential pressures up to 34 Bar (500 psi) of Nitrogen.
Part Number Configuration Breakdown
- Base Model: 148239 — 3300 XL 11mm Submerged Proximity Probe with 5/8-18 UNF thread and Tefzel tubing
- Unthreaded Length Option (-01): 0.1 inches unthreaded portion
- Overall Case Length Option (-18): 1.8 inches total case length
- Total Length Option (-50): 5.0 meters (16.4 feet) total system cable length
- Connector & Cable Option (-02): Miniature coaxial ClickLoc connector with standard cable
Technical Specifications Matrix
| Parameter Classification | Technical Engineering Metric |
|---|---|
| Brand & Series | Bently Nevada / 3300 XL Underwater Series |
| Model Number | 148239-01-18-50-02 |
| Probe Thread & Material | 5/8-18 UNF thread with 304 stainless steel case |
| Cable Protection | Tefzel tubing attached to probe case for fluid shielding |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Pressure Sealing Limit | Rated for 34 Bar (500 psi) Nitrogen differential pressure |
| Hazardous Approvals | ATEX / IECEx / CSA intrinsic safety (Zone 0) and non-incendive (Zone 2) |
Application Compatibility & Diagnostic Capabilities
- Target Machinery: Submersible pumps, hydraulic turbines, flooded gearboxes, and fluid-immersed industrial compressors.
- Diagnostic Capabilities: Detects shaft radial vibration, rotor whip, fluid-induced instabilities, and bearing clearance wear in wet or submerged operational zones.
Model Selection & Technical Comparison
| Comparison Model | Unthreaded & Length Specs | Technical Recommendation & Selection Guide |
|---|---|---|
| 148239-00-18-10-02 | 0.0 in unthreaded, 1.0 m total length | Select this alternative variant when your mounting setup requires a zero unthreaded portion combined with a shorter 1.0-meter cable run for compact junction housings. |
Logistics, Warranty & Fulfillment Terms
- Fulfillment Speed: Rapid dispatch within 24 to 48 hours.
- Global Shipping: Secure express courier delivery via FedEx, UPS, and DHL.
- Warranty Terms: Comprehensive 12-month factory defect warranty.
Frequently Asked Questions
Why must the connector end of the 148239 probe remain un-submerged?
While the probe body and Tefzel tubing seal the sensor tip against fluids, the miniature coaxial ClickLoc connector at the cable end is not liquid-tight and must reside in a dry junction box.
Can this 304 stainless steel probe be deployed in marine salt-water environments?
No, the 304 stainless steel case is not rated for salt-water applications; deployment should be restricted to fresh-water or compatible closed-loop industrial process fluids.
What is Global PLC Spare HUB's Insight on protecting Tefzel tubing during routing?
Global PLC Spare HUB recommends avoiding sharp pinch points and tight radius bends along the Tefzel tubing to prevent internal micro-fractures in high-flow fluid environments.
How does pressure rating verification work for high-pressure fluid applications?
Standard probes are pressure-rated to 34 Bar, but custom factory pressure testing should be requested if your operating differential pressure exceeds this baseline threshold.
What precautions are necessary when installing 11mm probes in hazardous explosive zones?
Ensure the system is installed using approved intrinsically safe zener barriers (drawing 141092) or galvanic isolators to maintain Zone 0 and Zone 2 compliance ratings.
