DO828 Industrial S800 DO828 Digital Relay Output Card Device
Manufacturer: ABB
Product No.: DO828
Condition： In stock
Product Type: Relay Output Module
Product Origin: SE
Payment: T/T, Western Union
Weight: 180g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Industrial System Architecture & Functionality
The DO828 (Part No: 3BSE069055R1) is a heavy-duty relay output card built for the S800 I/O framework. It features 16 individually isolated channels capable of handling up to 125V d.c. or 250V a.c. at 2A continuous current. Each channel integrates an optical isolation barrier, relay driver, and EMC suppression to safely drive high-voltage industrial actuators.
Global PLC Spare HUB's Insight & Field Experience
Managing high-inductive loads across distributed control nodes frequently introduces severe back-EMF transients that degrade standard switching hardware. Based on our field installation audits, deploying the DO828 with its complete channel-to-channel isolation eliminates cross-talk and ground fault propagation. Instrument engineers praise the integrated Output Safe State (OSP) function, which drives outputs to a secure pre-configured state upon communication loss.
Technical Parameters & Specifications Breakdown
| System Parameter | Operational Specification |
|---|---|
| Brand & Article No. | ABB | DO828 (3BSE069055R1) |
| Product Family | S800 I/O Digital Output Unit |
| Output Channels & Type | 16 channels, Form A Relay (Normally Open, NO) |
| Switching Voltage & Current | 5-125 V d.c. / 5-250 V a.c., 2A max continuous current |
| Galvanic Isolation | Individually isolated channel-to-channel and circuit common |
| Dielectric Test Voltage | 2000 V a.c. reinforced insulation rating |
| Maximum Field Wire Span | Up to 600 meters (656 yards) |
| Operational Power Loss | Typical 3.5 W dissipation |
| Thermal Operating Limits | 0°C to +55°C (ISA-S71.04 G3 corrosion grade coating) |
| Form Factor & Mass | Width: 45 mm, Depth: 102 mm, Height: 119 mm; Weight: 0.18 kg |
Target Equipment & Industrial Application Scenarios
- Direct control of high-capacity solenoid valves and heavy pneumatic actuators.
- Switching interface for heavy-duty industrial motor starters and contactors.
- Alarm annunciation panels requiring high-voltage relay isolation.
- Emergency shutdown (ESD) system interlocks in oil and gas production skids.
Advanced Diagnostics & Safety Supervision
- Real-time front panel LED monitoring for Module Fault, Run, OSP state, and individual channel status.
- 12V relay power converter monitor tracking internal bus health.
- Parameterizable relay supply voltage supervision reporting errors through the ModuleBus.
Fulfillment, Logistics & Warranty Terms
- Warranty Terms: Covered by a comprehensive 12-month replacement warranty from purchase date.
- Global Express Delivery: Fast, reliable shipping via FedEx, UPS, and DHL.
- Dispatch Window: Strict 24 to 48-hour order processing and dispatch turnaround.
Expert FAQ & Procurement Guide
Q: What specific ModuleTermination Unit (MTU) is required for physical wiring of the DO828?
A: The module requires the TU851 MTU matching the ED keying code configuration.
Q: How does the Output Safe State (OSP) function protect connected actuators?
A: When a controller communication fault or module error is detected, OSP forces all designated outputs into a safe, pre-programmed default position.
Q: Can each channel switch different external voltage potentials safely?
A: Yes, because all 16 channels are individually isolated from one another, they can switch completely separate AC or DC voltage sources simultaneously.
Q: Procurement Guide: When should I choose a relay output module over standard solid-state outputs?
A: Select this relay module when you need to switch heavy inductive loads, higher voltages up to 250V a.c., or require complete galvanic isolation between separate field loops.
Q: What hazardous location certifications does this unit carry?
A: It holds C1 Div 2 cULus, C1 Zone 2 cULus, and ATEX Zone 2 approvals, making it suitable for explosive gas atmospheres.
