The Emerson SE3008 represents a strategic bridge between compact efficiency and high-end performance within the DeltaV S-series ecosystem. Engineering teams select the SQ Controller specifically for small to moderate applications that require the same robust field-proven processor found in larger units. Its native support for CHARM-based Electronic Marshalling eliminates traditional wiring bottlenecks, allowing for a significantly reduced cabinet footprint.

Global PLC Spare HUB Review

Our technical assessment confirms the SE3008 excels in late-stage project flexibility. The forgiving architecture allows an immediate upgrade to the SX model without re-engineering hardware or logic. The Achilles Level 2 certification ensures it meets modern cybersecurity standards for critical infrastructure. It is ideal for modular skid builders and decentralized control strategies where rapid deployment is non-negotiable.

Product Overview

The Emerson SE3008 is a high-performance DeltaV SQ Controller designed for scalable distributed control systems. This module provides seamless communication and control functions across the field device network. It integrates effortlessly with the DeltaV S-series hardware to provide a reliable automation foundation.

• Support for Electronic Marshalling via CHARM technology
• Native 1:1 redundancy capability for high availability
• Screw-less DIN rail mounting for rapid cabinet assembly
• Plug-and-play Auto-Sense functionality for instant detection
• Execution of complex IEC-61131 programming languages

Technical Specifications

• Brand: Emerson
• Model: SE3008
• Series: DeltaV S-series
• Module Type: SQ Controller
• Device Signal Tag (DST) Limit: 750
• SCADA Tags: 3200
• User Memory: 48 MB
• Data Throughput: 2000 values/second (Sent), 250/second (Received)
• Execution Rates: 100ms to 60s adjustable intervals
• Temperature Range: -40 to 70°C (-40 to 158°F)
• Environmental Protection: IP 20 rating with G3 Conformal Coating
• External Connections: Dual 8-pin RJ-45 for Redundant Control Network

Installation and Compatibility

• Mounting: Snap-on S-series carriers for standard DIN rails
• Legacy Support: Compatible with configurations from earlier DeltaV versions
• System Upgrades: Direct hardware swap with SX Controllers for expansion
• I/O Support: Works with all S-series and CHARM based interfaces
• Addressing: Automatic addressing via the DeltaV Explorer database

Debugging and Maintenance

• Diagnostic Reporting: Real-time event reporting with accurate time stamps
• Hardware Detection: Automatic sensing of redundant modules with zero configuration
• Status Indicators: Dedicated LEDs for Power, Error, Active, and Network status
• Module Tracking: Parameter referencing by module name regardless of location
• Advanced Logic: Supports Neural Networks and Model Predictive Control (MPC)

Certifications and Compliance

• Safety: CE, FM, CSA certified for industrial environments
• Hazardous Areas: ATEX and IEC Ex II 3G Ex ec IIC T4 Gc
• Marine: IACS E10, ABS, and DNV Type Approval
• Cybersecurity: Wurldtech Achilles Communications Certification Level 2

Shipping and Warranty

• Shipping Methods: Available via FedEx, UPS, and DHL Express
• Dispatch Time: Ships within 24-48 hours after order confirmation
• Warranty: Includes a standard 12-month comprehensive warranty
• Packaging: Secure industrial-grade protective packaging

Typical Application Scenarios

• Modular Skid Packages: Ideal for standardized, repeatable process units
• Chemical Processing: Suitable for small to mid-sized batch control
• Energy Management: Effective for decentralized power or utility monitoring
• Oil and Gas: Reliable performance in extreme temperature environments

Buyer's Guide

• Capacity Planning: Choose the SE3008 if your project stays under 750 DSTs
• Future Proofing: Select this model if you anticipate potential capacity upgrades
• Footprint Optimization: Best for projects utilizing CHARMs to reduce cabinet space

Frequently Asked Questions

Can I replace an M-series controller with the SE3008?

Yes, you can use existing control strategies and system configurations from earlier systems.

Does the SE3008 require manual addressing for I/O modules?

No, the system uses Auto-Sense to address all components automatically in the database.

What happens if I exceed 750 DSTs in the future?

The SQ Controller allows a direct swap for an SX model without changing hardware design.

How does the SE3008 handle extreme humidity or corrosive air?

The module features G3 Conformal Coating to resist airborne contaminants and moisture.

Can this controller run Batch software?

Yes, the SE3008 fully supports Batch Software and advanced control algorithms.

Is the internal fuse replaceable by the user?

No, the 3.0 A internal fuses are non-replaceable to ensure hardware integrity.
