Delta ADP485-01 ADP485-01 DVP Series Communication Adapter

Delta ADP485-01 ADP485-01 DVP Series Communication Adapter

Manufacturer: Delta
Product No.: ADP485-01
Condition： En stock
Product Type: Communication Adapter
Product Origin: CN
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Cantidad

Selected quantity: 1

Tiempo estimado de entrega: 12-26 días (Internacional), 3-6 días (Estados Unidos).

Devolución dentro de los 30 días siguientes a la compra. Los aranceles e impuestos no son reembolsables.

Pago Seguro Garantizado

Engineering Overview & Connectivity Design

The ADP485-01 is a dedicated industrial network adapter and RS-485 hub manufactured by Delta Electronics. Designed to expand serial communication flexibility within automated control layouts, this active accessory provides a reliable hardware bridge for multi-drop network topologies.

According to Global PLC Spare HUB's Insight, automation engineers frequently deploy the ADP485-01 when expanding legacy fieldbus lines in high-noise manufacturing floors. Our hands-on field evaluations show that properly terminating the multi-port screw terminals drastically eliminates data packet collisions over extended cable runs.

Technical Specifications & Interface Layout

Manufacturer & Brand: Delta Electronics Industrial Automation
Model Number & MPN: ADP485-01 (Alternative ID: 2039-ADP485-01)
Accessory Classification: RS-485 Communication Hub / Signal Adapter
System Compatibility: Engineered specifically for use with Delta DVP Series Programmable Logic Controllers
Physical Interface Ports: 1 x DB9 serial port, 1 x RJ12 port, and 2 x screw terminal blocks for versatile wiring
Environmental & Compliance: Active product status, RoHS3 compliant, Moisture Sensitivity Level (MSL) Not Applicable
Packaging & Shipping Weight: Standard factory boxed packaging with a shipping weight of 2 kg

Diagnostics, Fault Tracing & Operational Reliability

Signal Integrity Tracking: Provides stable bus conversion to prevent communication timeouts between central controllers and remote field nodes.
Physical Troubleshooting: Easily inspect screw terminal connections and RJ12/DB9 pinouts using standard multimeter continuity tests to isolate bus faults.
Robust Isolation: Built to withstand industrial electrical transients when paired with proper cabinet grounding practices.

Express Logistics & Warranty Protection

Global Priority Dispatch: Shipped worldwide within 24 to 48 hours using leading international carriers including FedEx, UPS, and DHL.
Commercial Warranty: Fully covered by an extended 12-month replacement warranty against manufacturing defects.

Typical Industrial Applications & Equipment

Delta DVP PLC Networks: Interfacing remote HMI panels, variable frequency drives, and smart sensors to master controllers.
Material Handling Conveyors: Managing distributed serial communication loops across extended industrial factory floors.
Water Treatment Facilities: Linking remote telemetry units to central supervisory control stations via robust RS-485 lines.

Frequently Asked Questions

What controllers are compatible with the ADP485-01 adapter?
This hub is specifically designed for integration with Delta DVP Series PLCs and related industrial automation accessories.

How can I troubleshoot intermittent communication drops on the RS-485 network?
Verify that the screw terminal wiring polarity is correct, check for proper grounding of the shielded cable, and ensure terminating resistors are installed at both ends of the bus.

What physical connection ports are available on this hub?
The unit features a DB9 serial port, an RJ12 communication port, and two dual-screw terminal connection ports.

Buying Guide: When should I choose a multi-port RS-485 hub over direct wiring?
Select the ADP485-01 when your control scheme requires splitting serial lines or adapting between terminal blocks, RJ12, and DB9 connections without signal degradation.

Does the unit require an external power supply for basic operation?
As a passive adapter and hub accessory, it typically derives operational power through the connected controller communication interface loop.
