UT32A-000-11-00 Yokogawa UTAdvanced Digital Indicating Controller

Global PLC Spare HUB's Insight

• The UT32A-000-11-00 is a premier 1/8 DIN digital indicating controller in the Yokogawa UTAdvanced series.
• It bridges the gap between simple PID loops and complex logic with its integrated ladder sequence function.
• Engineers prefer the UT32A-000-11-00 for its 14-segment active color LCD that enhances onsite visibility.
• This unit provides a compact 65 mm depth, making it ideal for shallow instrumented panels.


Product Introduction

• The UT32A-000-11-00 simplifies complex process management through its intuitive navigation keys.
• It supports quick-setting functions to minimize the time required for initial commissioning.
• Please download the LL50A parameter setting software and UT32A manual to configure ladder programs.
• This controller offers universal I/O capabilities, supporting thermocouples, RTDs, and DC voltage/current inputs.

Technical Specifications

• Brand: Yokogawa
• Model Number: UT32A-000-11-00
• Series: UTAdvanced Digital Indicating Controller
• Display Technology: 5-digit, 14-segment active color LCD (White/Red PV display)
• Control Modes: PID control, Heating/Cooling control, and ON/OFF control with hysteresis
• Logic Capability: Built-in ladder sequence function as a standard feature
• Input Type: 1 Universal Input (DCV, TC, RTD, or mA)
• Analog Output: 4-20 mA DC or 0-20 mA DC with ±0.1% of span accuracy
• Response Time: Step response within 1.0 second for rapid process feedback
• Power Supply: 100 to 240 V AC (+10%/-15%) at 50/60 Hz
• Mounting Depth: 65 mm ultra-slim chassis for space-constrained cabinets
• Ingress Protection: IP66 front panel and NEMA4 hose-down test compliance
• Safety Standards: Certified to IEC/EN 61010-1 and UL 61010-1

Diagnostic and Monitoring Capabilities

• The UT32A-000-11-00 features a color-changing PV display to signal alarm states visually.
• Integrated guide displays show parameter names in plain alphabet letters for faster troubleshooting.
• Supports heater break alarms via external current transformers to prevent system downtime.
• Disconnection detection is available for slide resistance and 4-20 mA current inputs.

Ideal Equipment and Application Scenarios

• Plastic Extrusion: Precise thermal management using the heating/cooling PID control algorithms.
• Industrial Furnaces: Implementing safety interlocks directly through the UT32A-000-11-00 ladder logic.
• Environmental Chambers: High-resolution monitoring and tight-shut functions for precise atmosphere control.
• PLC Networking: Serving as a high-speed data node via CC-Link or RS485 serial communication.

Global PLC Spare HUB Review

• The UT32A-000-11-00 is a highly reliable "smart" controller for modern industrial loops.
• Its ability to handle local logic sequences often eliminates the need for a separate micro-PLC.
• The 14-segment display is a significant upgrade over traditional displays for clear parameter identification.
• This hardware is essential for plants focused on precision, safety, and reduced panel footprints.

Shipping and Warranty Logistics

• Carrier Options: Fast global delivery via FedEx, UPS, and DHL Express.
• Handling Time: Guaranteed dispatch within 24-48 hours of order verification.
• Warranty Policy: Protected by a 12-month comprehensive technical warranty.
• Condition: Ships in industrial-grade, anti-static protective packaging.

Professional FAQ and Purchasing Guide

• How do I program the ladder sequence for the UT32A-000-11-00?
• Programming is performed via a PC using the LL50A software (sold separately) and then downloaded to the controller.
• Can I use the UT32A-000-11-00 for position proportional control?
• Yes, this model supports position proportional relay output for driving motorized valves.
• What is the benefit of the "Active Color" LCD?
• It provides immediate visual feedback by changing the display color from white to red during an alarm.
• Does this model support 24V power supply?
• The standard model is 100-240V AC; for 24V AC/DC, please specify the /DC option when selecting your UT32A.
• Is the UT32A-000-11-00 suitable for side-by-side close mounting?
• While it can be mounted closely, the IP66 and NEMA4 ratings do not apply to side-by-side installations.
