TM5SDO8TA Schneider Electric Modicon 8-Point Discrete Output Module
Manufacturer: Schneider Electric
Product No.: TM5SDO8TA
Condition： In stock
Product Type: Discrete Output Module
Product Origin: FR
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The Schneider Electric Modicon TM5SDO8TA is a high-performance discrete output module engineered for advanced industrial automation. Featuring 8 transistor-based outputs, this unit provides precise control for complex machinery. It integrates flawlessly into Modicon architectures, ensuring reliable performance for Motion Controllers and Logic Controllers.
Technical Specifications
- Brand: Schneider Electric
- Model: TM5SDO8TA
- Series: Modicon TM5
- Output Type: 8 Discrete Transistor (Source Logic)
- Voltage Range: 24V DC (20.4–28.8V)
- Current Capacity: 2A per channel; 8A per output common
- Switching Frequency: Up to 500 Hz (Resistive Load)
- Response Time: ≤ 300 µs (State transition)
- Protection: Integrated short-circuit, overload, and reverse polarity protection
- Operating Temperature: 0°C to 60°C (Horizontal mounting)
- Environmental Rating: IP20 protection
- Electromagnetic Compatibility: Conforms to EN/IEC 61000-4 series
Compatibility and Installation
- System Compatibility: Designed for Modicon LMC058 and Modicon M258 controllers.
- Connection: Utilizes a 1-wire electrical interface for efficient wiring.
- Installation: Quick mounting on standard DIN rails.
- Diagnostics: Equipped with 8 yellow output status LEDs and dual power supply indicators (red/green).
Certifications and Compliance
- Safety Standards: UL 508, CSA 22-2 No 142/213, IEC 61131-2.
- Global Approvals: CULus, C-Tick, GOST-R, CE.
- Environmental: RoHS Compliant.
Global PLC Spare HUB's Insight
The TM5SDO8TA is a compact workhorse, ideal for high-density control cabinets. Our technical team recommends this module for packaging lines and material handling systems. Its high current capacity per channel allows direct driving of relays and small solenoids, reducing the need for external interface components.
Logistics and Guarantee
- Shipping: Fast international transit via FedEx, UPS, or DHL.
- Dispatch: Guaranteed processing and shipment within 24–48 hours.
- Warranty: Every unit is backed by a 12-month quality guarantee.
Frequently Asked Questions
What should I check if the output status LED is off?
Verify the 24V DC power supply input. Also, confirm the short-circuit protection hasn't triggered, as this disables outputs automatically.
Is this module suitable for high-vibration environments?
Yes, the TM5SDO8TA is engineered to meet rigorous vibration resistance standards for industrial control panels.
How do I ensure optimal module longevity?
Avoid exceeding the 500 Hz switching frequency and ensure adequate ventilation to remain within the 60°C thermal limit.
Buying Guide
Before purchasing, ensure your controller supports the Modicon TM5 I/O expansion series. Verify that your total load does not exceed the 8A common current limit. For high-speed applications, we strongly recommend using shielded cabling to maintain signal integrity against electromagnetic interference.
