The Pepperl+Fuchs KFD2-SR2-EX2.W represents a pinnacle in intrinsic safety engineering. It effectively bridges the gap between field-side sensors in explosive atmospheres and control-side logic. We recommend this module for critical infrastructure where fail-safe signal integrity is non-negotiable. It integrates seamlessly with PLC systems, DCS architectures, and SIS (Safety Instrumented Systems), providing robust galvanic isolation and fault diagnostics that minimize unplanned downtime.

Product Overview

The Pepperl+Fuchs KFD2-SR2-EX2.W is a high-performance, 2-channel switch amplifier designed for intrinsic safety applications. This device transfers digital signals from NAMUR sensors or mechanical dry contacts located in hazardous areas to non-hazardous control zones. It ensures reliable operation with SIL 2 functional safety compliance. The module features a reversible mode of operation and selectable line fault detection. Its compact design allows for efficient rail-mounting, making it ideal for high-density control cabinets.

Technical Specifications

• Manufacturer: Pepperl+Fuchs
• Model: KFD2-SR2-EX2.W
• Product Type: Switch Amplifier / Isolated Barrier
• Signal Type: Digital Input
• Safety Integrity Level: SIL 2 (SC 3) per IEC/EN 61508
• Frequency Response: ≤ 10 Hz
• Supply Voltage: 19 V DC to 30 V DC
• Power Consumption: ≤ 1 W
• Ambient Temperature: -40 °C to 70 °C
• Degree of Protection: IP20
• Dimensions: 20 mm x 119 mm x 115 mm
• Weight: 150 g
• Connection: Screw terminals for secure field wiring

Installation and Maintenance

• Mount the unit on standard 35 mm DIN rails according to EN 60715.
• Use the Power Rail system for simplified power distribution and collective error reporting.
• Configure operational parameters easily via front-side DIP switches.
• Utilize the integrated LED indicators for real-time status and fault diagnostics.
• Ensure wiring follows the specific terminal mapping to maintain intrinsic safety ratings.
• Perform routine checks of the relay contacts to ensure longevity beyond the rated 10^7 switching cycles.

Compatibility and Standards

• Compatible with all standard NAMUR proximity sensors and mechanical switches.
• Fully compliant with EMC Directive 2014/30/EU for industrial environments.
• Certified for hazardous area use under ATEX, IECEx, FM, and UL standards.
• Features reinforced galvanic isolation between all circuits up to 300 Veff.

Shipping and Warranty

• Processing Time: Orders ship within 24 to 48 hours.
• Logistics: We partner with FedEx, UPS, and DHL for global delivery.
• Quality Guarantee: Every unit includes a comprehensive 12-month warranty.
• Package Contents: 1x KFD2-SR2-EX2.W module and installation documentation.

Typical Applications

• Oil and Gas processing plants.
• Chemical and Petrochemical manufacturing.
• Offshore platforms and high-vibration industrial sites.
• Water treatment facilities requiring hazardous zone monitoring.

Frequently Asked Questions

Question: Can I disable line fault detection on this module?

Answer: Yes, you can disable the line fault detection feature using the integrated DIP switches on the front panel.

Question: What happens to the relay during a fault condition?

Answer: During a fault, the relay automatically reverts to its de-energized state, and the front LEDs signal the error according to NAMUR NE 44.

Question: Does this module support high-speed counting?

Answer: No, the maximum switching frequency is limited to 10 Hz, which is optimized for status monitoring rather than high-speed pulse counting.

Question: How do I know if the unit is failing?

Answer: Use the collective error message feature via the Power Rail or observe the status LEDs on the front display for immediate diagnostic feedback.

Buying Guide

• Verify your sensor type (NAMUR vs. dry contact) before configuration.
• Confirm the required SIL rating for your specific safety loop.
• Ensure the supply voltage matches the 20-30 V DC range to avoid operational instability.
• Consult the control drawing (e.g., 116-0035 for FM) if installing in FM-regulated environments.
• Contact our technical team if you require assistance with complex multi-channel safety architecture.
