IC694MDL752 Emerson RX3i Output Card | Fast Shipping
Manufacturer: GE Fanuc
Product No.: IC694MDL752
Condition： In stock
Product Type: Output Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
Global PLC Spare HUB Review
High-density automation architectures demand versatile discrete switching across complex process networks. Engineers deploy the IC694MDL752 output module to drive TTL and 24V DC loads simultaneously. This 32-channel unit features sinking negative logic switching across four isolated channel groups. Global PLC Spare HUB's Insight highlights its dual-voltage flexibility for controlling mixed industrial peripherals.
Technical Specifications
Global PLC Spare HUB's Insight
- Brand: Emerson Automation / GE Fanuc
- Model Number: IC694MDL752
- Product Series: PACSystem RX3i Series
- Module Classification: High-Density Sinking Discrete Output Module
- Channel Capacity: 32 Digital Outputs (4 groups of 8 channels)
- Operating Voltage Band: 4.75 to 5.25 VDC (TTL Mode), 10.2 to 28.8 VDC (12/24V Mode)
- Output Current Limit: 25 mA per point (TTL), 0.5 A per point (12/24V Mode)
- Group Current Ceiling: 3.0 Amps max per group common pin
- Signal Response Time: Fast 0.5 ms maximum switching response
- Backplane Power Draw: 260 mA maximum at 5 VDC
- Inrush Current Rating: 4.6 Amps maximum for 10 milliseconds
- Interface Connectors: Dual 24-pin Fujitsu FCN-365P024-AU style pin headers
- Compatible Wiring Cables: Pre-wired IC694CBL327 and IC694CBL328 assemblies
- Status Monitoring: 32 individually numbered channel LED status lights
Target Equipment & Industrial Applications
Global PLC Spare HUB Review
- Compatible Host Racks: Installs directly into local or remote PACSystem RX3i universal I/O slots.
- Application Scenario 1: Actuating high-speed solid-state relays in automated electronic assembly machinery.
- Application Scenario 2: Interfacing TTL-level logic boards with main industrial process controllers.
- Application Scenario 3: Driving 24V DC industrial solenoid valves across food packaging lines.
Diagnostic Capabilities & Maintenance Protocols
Global PLC Spare HUB's Insight
Engineers inspect the 32 individual LEDs to confirm channel state energization immediately during operation. Field experience indicates that improper external common wiring causes unexpected channel group overload trips. Clean pin connectors regularly to maintain low contact resistance in corrosive industrial environments.
Logistics, Warranty, and Package Contents
Global PLC Spare HUB Review
- Global Express Shipping: Dispatched within 24 to 48 hours using FedEx, UPS, and DHL couriers.
- Warranty Protection: Covered by a full 12-month operational replacement warranty.
- Package Inclusions: One IC694MDL752 32-point output module with factory protective packing.
Frequently Asked Questions
Global PLC Spare HUB Review
Can I operate different channel groups at different voltage levels on the same card?
Yes, each group common pin independently supports TTL 5V, 12V, or 24V DC field loads.
What pre-wired cable models connect to the front headers of this card?
Use Emerson cable assemblies IC694CBL327 or IC694CBL328 for reliable high-density field terminal wiring.
Why do my output LED indicators illuminate while field loads fail to actuate?
Check the external user power supply connections, as LED indicators draw power from the backplane bus.
What is the maximum current rating for a single channel group common?
Each group common pin handles up to 3.0 Amps maximum total load current.
How do I prevent voltage spikes when switching inductive loads with sinking outputs?
Install external suppression diodes across DC inductive solenoid coils to absorb back-EMF transients.
Engineering Selection Guide
Global PLC Spare HUB's Insight
Confirm whether your field devices require sinking or sourcing logic before ordering the IC694MDL752 module. Calculate total external power supply current requirements based on active output point density to prevent supply brownouts.
