IC200MDL244 GE Fanuc Versamax 8-Channel AC Discrete Input Module

IC200MDL244 GE Fanuc Versamax 8-Channel AC Discrete Input Module

Manufacturer: GE Fanuc
Product No.: IC200MDL244
Condition： In stock
Product Type: Discrete Input Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 250g
Shipping port: Xiamen
Warranty: 12 months

Quantity

Selected quantity: 1

Estimate delivery times: 12-26 days (International), 3-6 days (United States).

Return within 30 days of purchase. Duties & taxes are non-refundable.

Guaranteed Safe Checkout

Global PLC Spare HUB's Insight & Module Architecture

The IC200MDL244 serves as an 8-channel AC discrete input module within the Versamax automation platform. **GE Fanuc** designed this compact unit to interface high-voltage AC field sensors directly with CPU backplanes. Global PLC Spare HUB field engineers emphasize its individual channel isolation for high-noise electrical distribution environments. Maintenance professionals rely on its space-saving carrier footprint to maximize control panel density.

Technical Specifications & Operating Parameters

Technical Parameter	Engineering Specification
Brand & Series	GE Fanuc / Versamax
Part Number	IC200MDL244 (Also indexed as IC200MDL244)
Module Type	Discrete AC Input Module
Input Channel Count	8 individually isolated sourcing/positive logic inputs
Nominal Voltage & Range	240 Volts AC nominal, operating range 0 to 264 Volts AC
On-State Voltage Parameters	155 to 264 Volts AC with 7.0 milliamps minimum load per point
Backplane Current Draw	60 milliamps maximum at 5 Volts DC
Response Time & Isolation	1 cycle max response time, 500 VAC point-to-point and ground isolation
Physical Dimensions	110 x 66.8 x 50.0 Millimeters

Installation & Carrier Integration

Snap the IC200MDL244 module securely onto box-style, barrier-style, or spring-style I/O carriers.
Ensure backplane power distribution supports the 60 mA draw without voltage sag.
Terminate 240VAC field sensor wiring directly to carrier screw or spring terminals.
Verify mechanical alignment before latching the module housing onto the DIN rail base.

Module Diagnostics & Status Indicators

Monitor the 8 individually numbered front-panel LEDs to track active discrete input states.
Observe the dedicated backplane status LED to confirm healthy internal communication.
Check input voltage levels with a digital multimeter if a channel fails to register above the 155 VAC on-state threshold.
Verify point-to-point isolation boundaries if ground loop noise triggers phantom input readings.

Hardware Compatibility & Application Environments

Fully compatible with Versamax I/O racks and CPU controllers.
Interfaces AC limit switches, mechanical pushbuttons, and proximity sensors in industrial machinery.
Deploys in heavy power distribution substations, HVAC control panels, and motor control centers.

Logistics, Warranty & Package Contents

Package includes one IC200MDL244 input module and technical specification documents.
Backed by an industry-standard 12-month operational warranty.
Rapid worldwide dispatch within 24 to 48 hours via FedEx, UPS, and DHL.

Expert FAQ & Field Purchasing Insights

Question: What specific advantage do the individually isolated channels of the IC200MDL244 provide in heavy industrial plants?

Answer: Individual isolation prevents multi-channel electrical cross-talk and shields internal logic from transient voltage spikes originating on separate 240VAC field circuits.

Question: How should technicians troubleshoot an input channel that remains unlit despite 240VAC applied at the terminal?

Answer: Verify that the input current meets or exceeds the 7.0 mA minimum load threshold and check for loose carrier spring connections.

Question: Buying Guide: What carrier styles should engineers select when deploying this module in high-vibration environments?

Answer: We recommend spring-style or box-style I/O carriers to maintain constant wire tension and prevent loosening under continuous mechanical shock.

Question: Does this module require an external user-supplied power source for its internal logic circuitry?

Answer: No, internal operational power is derived directly from the system backplane, drawing a maximum of 60 milliamps at 5 Volts DC.

Question: Can the IC200MDL244 safely interface with sinking-type DC sensors?

Answer: No, this is specifically an AC input module rated for 240VAC sourcing logic applications and cannot process standard DC input signals.
