DS200SDCCG5A GE EX2000 Drive Control Card Exciter Processor Module
Manufacturer: GE
Product No.: DS200SDCCG5A
Condition： In stock
Product Type: Exciter Processor Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
DS200SDCCG5A Digital Exciter Drive Control Card
GE DS200SDCCG5A functions as the primary processing platform within EX2000 excitation control systems.
The board belongs to the technically mature EX2000 and Mark V industrial control architecture.
This controller combines multiple processors, memory resources, and configurable interfaces.
The hardware supports complex excitation regulation and industrial drive management.
Engineers deploy this module in mission-critical turbine and motor control environments.
System Processing Architecture
- Three independent 16-bit processing units
- Dual-ported RAM communication structure
- Dedicated motor control computation resources
- Integrated signal management capability
- Expandable processing interface design
- Real-time industrial control execution
- Multi-layer firmware configuration architecture
Processor Configuration Details
DS200SDCCG5A integrates specialized processors for different operational tasks.
- 80C186 Microcontroller: System operations and interface management
- 80C196 Processor: Motor control and regulation loops
- TMS320C25 DSP: Advanced mathematical algorithm execution
The DSP activates when applications require additional computational performance.
Technical Specifications
- Brand: General Electric
- Model: DS200SDCCG5A
- Series: EX2000 / Mark V
- Module Type: Digital Exciter Drive Control Card
- Functional Abbreviation: SDCC G5A
- Primary Application: Excitation and drive control
- Processor Quantity: 3 onboard microprocessors
- Signal Channels: 16
- Analog Output Range: 0–20 mA
- Frame Rate: 100 Hz
- Onboard Software: 4 EPROMs and 1 EEPROM
- EPROM Locations: U11, U12, U22, U23
- EEPROM Location: U9
- Memory Structure: Dual-ported RAM architecture
- Communication Expansion: Auxiliary card support
- Board Weight: Approximately 1.5 lbs
- Configuration Method: Hardware jumpers and software tools
- Jumper Types: JP and WJ configuration jumpers
- Manual Reference: GEI-100029D
- Country of Origin: United States
- Availability: In Stock
Supported Expansion Boards
- DS215SLCC LAN Communications Card
- 531X306LCC LAN Communications Card
- 531X309SPC Signal Processor Card
- DS200SPCB Multibridge Signal Processor Card
The architecture supports flexible industrial control expansion requirements.
Engineering Software Environment
- ST2000 configuration platform
- GE Control System Toolbox
- LynxOS Drive Configurator
These tools support firmware configuration, parameter management, and diagnostics.
Diagnostic Capability
DS200SDCCG5A provides advanced monitoring and processing diagnostics for industrial drive systems.
- Processor communication monitoring
- EEPROM parameter verification
- Signal processing diagnostics
- Control loop status analysis
- Memory integrity monitoring
- Drive algorithm execution supervision
- I/O communication diagnostics
- Expansion board interface monitoring
Global PLC Spare HUB's Insight
This module remains highly valued in excitation control modernization projects.
The triple-processor structure improves operational separation and processing efficiency.
Industrial users benefit from stable regulation loop execution under dynamic loads.
The onboard memory architecture supports dependable parameter retention.
Engineers appreciate the modular expansion flexibility for custom applications.
The DSP-assisted control architecture improves performance during complex drive regulation tasks.
Recommended Equipment and Applications
- EX2000 excitation systems
- Industrial motor drive systems
- Turbine excitation control cabinets
- Heavy industrial process automation
- Power generation facilities
- High-speed motor regulation platforms
- Industrial energy management systems
- Advanced process synchronization systems
Installation and Configuration Notes
- Install the board in grounded industrial control cabinets.
- Do not modify factory jumper settings without documentation verification.
- Use approved software tools for firmware configuration.
- Inspect auxiliary card alignment before installation.
- Verify EPROM seating during maintenance procedures.
- Maintain proper cabinet ventilation for thermal stability.
- Separate control wiring from high-voltage conductors.
Packaging Information
- 1 × DS200SDCCG5A Drive Control Card
- 1 × Anti-static industrial packaging
- 1 × Product inspection documentation
Shipping Services
- FedEx international delivery
- UPS global express shipping
- DHL industrial logistics support
- 24–48 hour dispatch availability
- Secure export-grade protective packaging
12-Month Warranty Support
Every supplied module includes a 12-month warranty.
Technical assistance supports configuration and operational troubleshooting.
Warranty coverage supports manufacturing-related operational abnormalities.
Professional FAQ
Why does this controller use three separate processors?
Each processor manages dedicated control functions for improved real-time performance.
What operational issue commonly affects excitation control boards?
Improper grounding and unstable cabinet temperatures often impact signal stability.
What should engineers verify before replacing this module?
Confirm firmware compatibility, auxiliary board requirements, and system configuration parameters.
Which applications benefit most from the onboard DSP processor?
High-speed regulation and math-intensive drive systems gain the greatest performance advantage.
What maintenance practice improves long-term operational reliability?
Regular inspection of EPROM seating and cabinet airflow significantly improves stability.
