DS200FSAAG2ABA GE Field Supply Amplifier Board | Drive Control Module
Manufacturer: GE
Product No.: DS200FSAAG2ABA
Condition： In stock
Product Type: Drive Control Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The DS200FSAAG2ABA is a vital Field Supply Gate Amplifier Board developed by General Electric. Engineered specifically for the Drive Control product series, this module ensures the precise amplification of control signals essential for thyristor bridge management. It functions as the critical link between the SDCC controller and the field exciter modules, facilitating efficient power conversion in high-demand industrial motor drive systems.
Technical Specifications
- Manufacturer: General Electric
- Series: Drive Control
- Part Number: DS200FSAAG2ABA
- Type: Field Supply Gate Amplifier Board (FSAA)
- Dimensions: 52 mm x 62 mm
- Operating Temperature: 0°C to 50°C
- Connectivity: 10-pin terminal connector, multiple test points
- Circuit Components: 5 jumpers, 2 fuses, integrated transistor/IC signal amplification logic
Engineering Insights and Diagnostic Capabilities
The DS200FSAAG2ABA is engineered to maintain signal integrity in environments where voltage suppression and noise immunity are critical. It works in conjunction with MOVs (Metal Oxide Varistors) and AC/DC line filters to protect the thyristor bridge from transient spikes. The board's design allows for real-time monitoring via onboard test points, enabling maintenance technicians to verify amplification ratios and firing pulse stability during operational load tests.
Global PLC Spare HUB's Insight
From an installation perspective, the DS200FSAAG2ABA is often underestimated regarding its role in long-term drive stability. We have observed that many premature drive failures originate from degraded gate pulse signals caused by aged capacitors on this board. We recommend replacing this module if your drive exhibits erratic torque control or if the firing angle becomes inconsistent under fluctuating load conditions.
Typical Applications
- Large-scale Industrial Motor Drive Systems (G, C, J, K, L, M Frame)
- Thyristor Bridge Firing and Gate Control
- Field Exciter Module Signal Conditioning
- Regenerative DC Drive Applications
Ordering and Logistics
- Warranty: 12-month industry-leading replacement warranty.
- Shipping: Global delivery via premium carriers: FedEx, UPS, and DHL.
- Dispatch: Rapid 24-48 hour lead time for all in-stock inventory.
- Package Includes: DS200FSAAG2ABA Amplifier Board and documentation.
Frequently Asked Questions
What is the primary function of the test points on the board?
The test points are designed for field technicians to measure gate signal voltage levels, allowing for rapid isolation of faults within the gate pulse transformer driver circuit.
Is the DS200FSAAG2ABA compatible with all frame sizes?
The module is designed for use across multiple frame sizes (G, C, J, K, L, M), but users must cross-reference their specific drive's elementary diagrams to verify the correct thyristor bridge configuration.
What does it mean if my board's fuse is repeatedly blowing?
Repeated fuse failure typically indicates a shorted SCR module within the bridge or a localized short circuit within the gating transformer driver stage; inspect the thyristor bridge before replacing the board.
How should I store this board as a long-term spare?
Store the unit in an anti-static bag within a climate-controlled environment to prevent oxidation of the 10-pin terminal connector and the degradation of integrated ICs.
Can I perform a hot-swap of this board while the drive is active?
No, for safety and equipment protection, the drive power must be fully discharged and locked out per your facility's safety protocols before removing or installing the DS200FSAAG2ABA.
Selection and Installation Guide
- Verify that the incoming power supply matches the specific drive frame rating before connection.
- Check the status of the two onboard fuses; if they show signs of thermal fatigue, replace them with the exact GE-specified rating.
- Ensure the board is seated firmly in the interface slot, and secure all cabling to the 10-pin connector to prevent intermittent connection failures due to cabinet vibration.
