DL100-21AA2212 SICK Dx100 Distance Sensor | PROFINET Long Range

Product Overview

• The DL100-21AA2212 is a high-performance laser distance sensor designed for long-range industrial positioning.
• Part of the Dx100 Series, it offers a massive 100-meter range with millimetric accuracy.
• Equipped with a PROFINET interface, this sensor supports high-speed data exchange for real-time automation.
• The rugged aluminum construction ensures the DL100-21AA2212 thrives in demanding crane and logistics environments.

Technical Specifications

• Brand: SICK
• Model: DL100-21AA2212
• Series: Dx100 Series
• Measurement Range: 0.15 m to 100 m on reflective tape
• Accuracy: ± 2 mm absolute precision
• Interface: PROFINET (Network Load Class III)
• Output Type: 2 x Push-pull (PNP/NPN) for distance/speed
• Response Time: Ultra-fast 2 ms measurement response
• Light Source: Visible red laser (Laser Class 2)
• Enclosure Rating: IP65 for dust and water resistance

Installation & Compatibility

• Standard male connector design facilitates quick integration into industrial PROFINET networks.
• Compact footprint (69.4mm width) allows for installation on narrow shuttle vehicles and gantries.
• Fully compatible with Siemens, Rockwell, and other major PLC systems supporting PROFINET communication.
• Direct configuration is available via the integrated 6-digit dot matrix display and user-friendly buttons.

Diagnostic Capabilities

• The DL100-21AA2212 monitors internal temperature to alert against overheating.
• Contamination detection notifies operators when the PMMA window needs cleaning to prevent signal degradation.
• Predictive maintenance alerts signal when the laser reaches the end of its operational lifecycle.
• Integrated LEDs provide immediate visual feedback on network status and power health.

Application Scenarios

• Positioning of Automated Storage and Retrieval Systems (AS/RS) in large-scale warehouses.
• Long-travel distance monitoring and collision avoidance for overhead gantry cranes.
• Real-time speed and position tracking for automotive transfer carriages.
• Accurate height measurement for container spreaders in port automation sectors.

Global PLC Spare HUB’s Insight

• The DL100-21AA2212 stands out due to its 15 m/s movement speed tolerance.
• This Dx100 Series sensor is engineered for high-dynamic applications where acceleration is a factor.
• Our engineers recommend this module for mission-critical paths where 100% uptime and millimetric precision are mandatory.

Shipping & Warranty

• Warranty Period: 12-month quality guarantee included with all DL100-21AA2212 units.
• Express Shipping: Global delivery via DHL, FedEx, and UPS.
• Handling Time: Orders are dispatched within 24 to 48 hours.
• Condition: Only premium-grade components, ensuring maximum MTTFd of 101 years.

FAQ & Selection Tips

• What is the best way to choose between the Dx100 variants?
• Select the DL100-21AA2212 High Feature model if you require PROFINET and a full 100m range.
• Does ambient light affect the measurement accuracy?
• No, this sensor features ambient light immunity up to 100,000 lx, suitable for bright indoor or outdoor use.
• Is reflective tape included in the box?
• Reflective tape is typically sold separately to match the specific distance requirements of your track.
• Can I use this sensor in sub-zero freezer warehouses?
• Yes, the standard operating range goes down to -20 °C without additional heating equipment.
• How do I handle mounting in high-vibration zones?
• The DL100-21AA2212 is tested against EN 60068 standards for shock and noise; use the heavy-duty bracket for best results.
