6AR1303-0AA01-0AA0 Siemens Interface Module Ethernet Automation

Technical Engineering Data

The 6AR1303-0AA01-0AA0 is a specialized industrial interface module designed to bridge field-level automation equipment with Ethernet-based network architectures. Engineered for operational longevity, this unit ensures stable data packet delivery at a consistent 10 Mbit/s transmission rate, maintaining high reliability in standard industrial environments.

Key Specifications

• Manufacturer: Siemens
• Part Number: 6AR1303-0AA01-0AA0
• Category: I/O Modules / Communication Interface
• Interface: Ethernet Network Compatibility
• Transmission Speed: 10 Mbit/s
• Operational Temp: 0°C to +60°C
• Protection Class: IP20
• Weight: 0.49 lbs (approx. 222 g)
• Standards: CE Certified

Diagnostic Capability and Environmentals

• Operational Integrity: Stable performance within 0–80% RH humidity, ensuring effective indoor cabinet operation.
• Environmental Tolerance: Designed for indoor automation enclosures requiring solid-body ingress protection (IP20).
• System Diagnostics: Provides core connectivity status, allowing master controllers to identify link states through Ethernet handshake protocols.
• Robustness: High vibration and thermal resistance suitable for standard manufacturing facility footprints.

Global PLC Spare HUB Insight

The 6AR1303-0AA01-0AA0 remains a reliable legacy communication bridge. Our engineers at Global PLC Spare HUB value its simplicity in point-to-point Ethernet integration.

• Ideal Equipment: Legacy PLC controller networks, distributed data collection gateways, and serial-to-Ethernet transition interfaces.
• Application Fit: Best utilized in environments where robust, non-complex Ethernet communication is required for monitoring static automation processes.

Logistics and Warranty

• Shipping Services: We facilitate worldwide distribution via FedEx, UPS, and DHL.
• Fulfillment: Standard lead times ensure dispatch within 24-48 hours.
• Warranty Support: Includes a 12-month functional quality warranty.

Expert Frequently Asked Questions (FAQ)

Is this module suitable for high-speed deterministic control tasks?
With a 10 Mbit/s transmission limit, this module is optimized for steady data transfer rather than time-critical, high-bandwidth motion control feedback.

Does the module require external power filtering for the Ethernet connection?
The unit is designed for internal cabinet use; however, shielding your Ethernet cabling is recommended to prevent EMI interference in high-voltage zones.

What does the IP20 rating imply for my installation environment?
It indicates the module is protected against objects larger than 12.5 mm; it should be installed inside a sealed control enclosure to prevent dust and liquid ingress.

When selecting a replacement, what should I verify regarding my network topology?
Ensure your switch port is capable of forced 10 Mbit/s negotiation if auto-negotiation fails, as this is a legacy-standard interface.

How should I interpret non-condensing humidity requirements?
Keep the module away from cooling exhaust or temperature-swing areas to prevent internal moisture accumulation, which can trigger connection instability.
