330450-60 Bently Nevada Velocity Transducer 3300 XL High Temperature Sensor
Manufacturer: Bently Nevada
Product No.: 330450-60
Condition： In stock
Product Type: Velocity Transducer
Product Origin: USA
Payment: T/T, Western Union
Weight: 953g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Introduction
330450-60 from Bently Nevada delivers stable vibration monitoring for critical rotating machinery.
This industrial accelerometer supports high-temperature operation and hazardous area applications.
The sensor combines rugged stainless steel construction with precision vibration signal output.
330450-60 supports long cable transmission without signal degradation.
The hermetically sealed structure improves reliability in harsh process environments.
The design targets continuous condition monitoring in heavy industrial systems.
Configuration Breakdown
| Model | 330450-60 |
| Series | 3300 XL Acceleration Transducer Series |
| Suffix -60 | 6 Metre Integral Cable Length |
| Manufacturer | Bently Nevada |
| Origin | Made in U.S.A |
| Sensor Type | Industrial Accelerometer / Velocity Monitoring Sensor |
| Installation Type | Permanent Machine Condition Monitoring |
Technical Architecture
- Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5%
- Acceleration Range: 785 m/s² peak overall acceleration
- Amplitude Linearity: ±2% up to 80 g peak
- Frequency Response: 15 Hz to 10 kHz ±3 dB
- Extended Frequency Stability: 40 Hz to 4 kHz ±5%
- Noise Floor: 0.059 m/s² rms
- Transverse Sensitivity: Less than 5%
- Mounted Resonance: Greater than 15 kHz
- Maximum Cable Distance: 305 metres without signal loss
- Input Voltage: -24 ±0.5 Vdc
- Bias Current: 2 mA nominal
- Output Bias Voltage: -12 ±0.5 Vdc
- Grounding: Electrically isolated case
- Connector Type: 3-pin Mil-C-5015 hermetically sealed connector
- Housing Material: 300 series stainless steel
- Weight: 953 grams
- Minimum Bend Radius: 51 mm
Environmental Performance Structure
- Sensor Operating Temperature: -55°C to +400°C
- Electronic Housing Temperature: -55°C to +100°C
- Shock Survivability: 24,535 m/s² peak
- Humidity Resistance: 100% non-submerged environment
- Protection Design: Hermetically sealed enclosure
- Ingress Protection: Type 4X enclosure structure
- Anti-Interference Design: Isolated housing minimizes electrical noise impact
Hazardous Area Certifications
| Certification | Classification |
| ATEX / IECEx | Zone 0 / Zone 1 Approved |
| Ex ia IIC T4 | Intrinsically Safe Installation |
| Class I Div 1 | Groups A, B, C, D |
| Class II Div 1 | Groups E, F, G |
| Class III Div 1 | Industrial Dust Environment |
| Ex ec IIC T4 | Zone 2 Installation |
| Operating Ambient | -40°C to +100°C |
Temperature Classification Tree
-
T4 Classification
- Equipment: Electrical Housing
- Range: -40°C to +100°C
-
T1 Classification
- Equipment: Sensor and Cable
- Range: -40°C to +400°C
-
T4 Classification for 350900
- Equipment: Sensor and Cable
- Range: -40°C to +482°C
Diagnostic Capability
- Detects abnormal vibration growth in rotating equipment
- Supports predictive maintenance analysis strategies
- Improves bearing and shaft fault identification
- Supports continuous machine health monitoring
- Maintains stable signal output under high-temperature conditions
- Helps reduce unplanned equipment shutdown events
Recommended Equipment Applications
- Steam turbines
- Gas compressors
- Industrial pumps
- Cooling tower fans
- Gearbox monitoring systems
- Petrochemical rotating equipment
- Power generation machinery
- Offshore process systems
- Refinery critical asset monitoring
Global PLC Spare HUB Review
Bently Nevada 330450-60 performs reliably in high-vibration industrial environments.
The sensor structure handles extreme temperatures while maintaining measurement stability.
Maintenance engineers value the low-noise output and rugged stainless-steel construction.
The long cable capability simplifies installation across large process facilities.
This model fits demanding predictive maintenance systems requiring stable vibration diagnostics.
The intrinsically safe design supports hazardous area installations in oil and gas industries.
Installation Recommendations
- Use rigid mounting surfaces for accurate vibration transmission
- Protect cable routing from excessive mechanical stress
- Verify hazardous area compliance before energizing circuits
- Use certified intrinsically safe barriers where required
- Maintain connector sealing integrity during installation
Packing Information
- 1 × 330450-60 Accelerometer Sensor
- 1 × Protective industrial packaging
- 1 × Product inspection documentation
Warranty & Shipping
- 12-month warranty support included
- Technical assistance available during warranty period
- Fast dispatch within 24-48 hours
- Worldwide shipping via FedEx, UPS, and DHL
- Secure export packaging for industrial transportation
Professional FAQ
Why does cable routing matter in vibration monitoring systems?
Poor cable routing increases noise interference and unstable vibration readings.
How do engineers select between velocity and acceleration monitoring?
Acceleration sensors perform better for high-frequency fault detection applications.
What installation mistake reduces measurement accuracy most often?
Loose mounting surfaces create resonance distortion and inaccurate vibration data.
Which machines benefit most from 330450-60?
High-speed rotating assets with continuous operational duty cycles benefit most.
What should buyers confirm before purchasing this sensor?
Verify temperature range, hazardous area classification, and monitoring system compatibility.
