330130-085-11-05 Bently Nevada Extension Cable 3300 XL Series Shielded
Manufacturer: Bently Nevada
Product No.: 330130-085-11-05
Condition： In stock
Product Type: Extension Cable
Product Origin: USA
Payment: T/T, Western Union
Weight: 323g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The 330130-085-11-05 is an industrial-grade extension cable engineered by Bently Nevada. Part of the 3300 XL Series, this assembly connects high-frequency eddy current proximity probes to Proximitor sensors. It ensures signal integrity in harsh monitoring environments while resisting severe mechanical stress and chemical exposure.
Global PLC Spare HUB's Insight & Engineering Field Experience
In our field experience supporting turbo-machinery protection systems, signal degradation often stems from improper cable length matching and fluid breaching at connector joints. When deploying the 330130-085-11-05 in heavy industrial applications, always ensure that the combined probe and extension cable lengths sum up precisely to match your Proximitor sensor calibration rating. Furthermore, avoid using silicone tape near turbine oil zones; instead, rely on the integrated Armored FluidLoc jacket to maintain long-term hermetic sealing.
Configuration Breakdown & Suffix Options
| Configurable Option | Selected Suffix Code | Engineering Specification |
|---|---|---|
| Base Model Number | 330130 | 3300 XL 8 mm Extension Cable core architecture |
| Cable Length Option | -085 | 8.5 meters (27.9 feet) physical length |
| Protector & Jacket Option | -11 | Armored FluidLoc cable configuration |
| Hazardous Approvals | -05 | CSA, ATEX, and IECEx multi-agency compliance |
Technical Specifications
| Parameter Category | Technical Metric | Operational Value |
|---|---|---|
| Physical Weight | Standard Cable Density | 34 g/m (0.4 oz/ft) [Total: 0.289 kg] |
| Armored Cable Density | 103 g/m (1.5 oz/ft) [Total: 0.875 kg] | |
| DC Electrical Resistance | Core Conductor (RCORE) | 1.87 ± 0.28 Ω across 8.5m length |
| Outer Conductor (RJACKET) | 0.56 ± 0.11 Ω across 8.5m length | |
| Electrical Properties | Extension Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Output Impedance | 50 Ω nominal resistance | |
| Operating Environment | Power Supply Range | -17.5 Vdc to -26 Vdc (12 mA max) |
| Humidity Stability | <3% change in Average Scale Factor (ASF) at 93% humidity |
Recommended Equipment & Application Scenarios
- Critical Turbomachinery: Steam, gas, and hydro turbine-generators.
- Rotary Equipment: Centrifugal compressors, boiler feed pumps, and large industrial fans.
- Heavy Gearboxes: High-load industrial gear drives requiring precise vibration tracking.
- Hazardous Zones: Petrochemical processing plants requiring ATEX/IECEx certified wiring.
Diagnostic Capabilities & System Performance
- Shaft Vibration Monitoring: Tracks radial vibration to detect rotor unbalance and misalignment.
- Axial Position Tracking: Measures thrust collar displacement to prevent catastrophic rubbing.
- High-Frequency Response: Maintains linear range from 0.25 mm to 2.3 mm (10 to 90 mils) without signal attenuation.
- Environmental Robustness: Prevents oil migration through cable interiors using specialized FluidLoc technology.
Warranty, Shipping & Fulfillment
- Commercial Guarantee: Backed by a comprehensive 12-month factory warranty.
- Order Turnaround: Rapid processing with dispatch within 24 to 48 hours.
- Global Logistics: Express worldwide shipping supported via FedEx, UPS, and DHL.
Professional Frequently Asked Questions (FAQ)
Q: Why is precise total length matching critical when installing the 330130-085-11-05?
A: Proximitor systems are calibrated as a matched set. The sum of the probe length and extension cable length must strictly equal the total calibrated length designed for the Proximitor sensor to prevent calibration errors.
Q: How does the FluidLoc option protect against compressor oil leaks?
A: The internal cabling structure blocks capillary fluid migration, preventing internal oil from wicking through the cable jacket into the terminal housing.
Q: Can I shorten or splice an 8.5-meter extension cable during installation?
A: No. Altering cable length changes total electrical capacitance and resistance, which disrupts signal scaling and invalidates system accuracy.
Q: What are the best practices for selecting extension cables in high-vibration zones?
A: Opt for armored variants like the -11 suffix model to protect against mechanical abrasion, sharp metal chips, and physical crushing in tight machinery casings.
Q: How do I verify DC loop resistance during routine maintenance checks?
A: Disconnect the cable ends and measure core-to-core resistance using a calibrated multimeter. Verify that the recorded value falls within the nominal threshold of 1.87 ± 0.28 Ω.
Tags
Q: Are these parts 100% original and new?
A: Yes. Every component is guaranteed to be 100% original, brand-new, and factory-sealed. We also provide a 12-month comprehensive warranty for your peace of mind.
Q: How fast is the shipping to my country?
A: For in-stock items, we offer same-day dispatch. International express shipping (DHL/FedEx/UPS) typically delivers within 3–5 business days worldwide.
Q: Can I get a formal quotation with shipping costs?
A: Absolutely. Our sales team is ready to provide a detailed Proforma Invoice (PI) including the most competitive shipping rates for your location.
Q: Do you offer discounts for bulk orders?
A: We provide volume-based pricing for large projects or multiple-item orders. Please contact us to get our Best Price Guarantee.
12-Month Comprehensive Warranty
Every part supplied by Global PLC Spare Hub is covered by a 12-month warranty from the date of invoice.
- Coverage: Functional defects and hardware failures under normal operating conditions.
- Commitment: We provide immediate repair, replacement, or a full refund for any verified defective components to minimize your operational downtime.
Returns & Exchange Policy
We offer a 30-day return policy to ensure you receive the exact part your system requires.
- Eligibility: Returns are accepted for uninstalled items in their original, factory-sealed packaging.
- RMA Process: Please contact our support team to obtain a Return Merchandise Authorization (RMA) number before shipping.
- Fast Processing: Refunds or exchanges are processed within 3–5 business days after the returned item passes our technical inspection.
Need Technical Assistance?Not sure if this part is compatible with your system? [Consult our Engineers] before purchasing to ensure 100% compatibility.
