RECA-01 ABB EtherCAT Adapter | Single-Port Drive Communication Module

RECA-01 | ABB Single-Port EtherCAT Drive Communication Adapter

The ABB RECA-01 is an EtherCAT communication adapter designed for compatible ABB drives. It installs into an option slot on the drive control board and connects the drive to an EtherCAT industrial Ethernet network. The adapter supports full-duplex communication at 100 Mbit/s. Two RJ-45 connectors provide the network interface, while a 34-pin parallel bus connector links the adapter to the drive control board. The RECA-01 supports integration between compatible drives, EtherCAT controllers, and industrial automation systems. Engineers configure its settings through drive parameters.

Product Identification and Technical Overview

Engineering note: The adapter uses the drive control board for power. Confirm the exact drive model, supported option slot, and hardware manual before installation. The stated lifetime is an estimate, not a guaranteed service life.

EtherCAT Network Design

The RECA-01 provides a 100BASE-TX EtherCAT interface for compatible network devices. Its internal termination simplifies the adapter's network design, while the external cabling must meet the applicable installation requirements.

Use industrial Ethernet cabling suitable for the installation environment. Keep each segment within the specified 100 m limit. Follow the EtherCAT network topology and cabling rules in the relevant system documentation.

Mechanical Design and Environmental Requirements

• Compact integration: The module fits into a designated option slot on the drive control board.
• IP20 protection: The adapter suits protected control cabinets and electrical enclosures.
• Conformal-coated PCB: The printed circuit board has a conformal coating, as specified by ABB.
• Ambient conditions: The applicable drive hardware manual defines the operating environment.
• UL/CSA material compliance: The specification identifies UL/CSA-approved materials.

IP20 does not provide protection against water ingress. Install the drive and adapter in an enclosure that meets the site's environmental and safety requirements.

Installation and Parameter Configuration

1. Confirm compatibility: Check that the target ABB drive supports the RECA-01.
2. Isolate power: Follow the drive manual's shutdown and discharge procedures.
3. Inspect the option slot: Check the control board connector and mounting area.
4. Install the adapter: Seat the 34-pin interface correctly in the designated slot.
5. Connect the network: Use the RJ-45 connectors and suitable CAT 5 cabling.
6. Configure drive parameters: Apply the required communication settings according to the drive manual.
7. Check the network: Verify the EtherCAT controller recognizes the node and completes the required startup sequence.
8. Test operation: Confirm drive communication, command handling, and status feedback before production use.

Do not insert or remove the adapter while the drive remains energized. Use the manufacturer's installation instructions for connector orientation, fastening, and parameter setup.

Diagnostic Approach and Troubleshooting

The supplied specifications do not identify dedicated status LEDs or their diagnostic codes for the RECA-01. Engineers should therefore use the drive's diagnostic parameters and EtherCAT master diagnostics rather than assume a particular LED arrangement.

Field example: During a drive replacement, the controller may fail to establish EtherCAT communication even when the adapter fits the option slot. An engineer should verify the exact drive compatibility, check the network connections, and review the controller's startup diagnostics. This process helps distinguish hardware mismatch from cabling or configuration errors.

Equipment Compatibility and Industrial Applications

The ABB RECA-01 is intended for ABB drive models that explicitly support this adapter. Its EtherCAT interface can serve a range of industrial motion and process-control applications.

• PLC-controlled drive systems: Exchange supported drive commands and status data with an EtherCAT master.
• Automated production lines: Integrate compatible drives into coordinated machine-control architectures.
• Conveyor equipment: Support drive communication within material handling systems.
• Packaging machinery: Connect supported drive hardware to EtherCAT-based machine controllers.
• Industrial pumps and fans: Integrate compatible drives into centralized automation systems.
• Machine retrofits: Add EtherCAT connectivity when the drive hardware and control architecture support the adapter.
• Maintenance spares: Keep a verified adapter available for supported drive installations.

Compatibility warning: EtherCAT compliance does not guarantee universal drive compatibility. Check the exact ABB drive model, firmware requirements, supported functions, and configuration instructions before ordering.

Global PLC Spare HUB's Insight

For drive engineers, the RECA-01 provides a direct path from a compatible ABB drive to an EtherCAT control network. The main selection risks involve drive compatibility, network topology, and parameter configuration. Consider a production line that replaces an existing drive while retaining the EtherCAT network. The replacement adapter must match the supported drive hardware. The engineer must also confirm the controller configuration and the existing cable route. A matching connector alone does not prove functional compatibility. During commissioning, verify the module installation first. Then check network recognition, controller startup status, and drive parameter settings. If communication fails, isolate the problem by checking the drive interface, network cabling, and master configuration in sequence. For maintenance teams, recording the complete product ID, drive model, firmware details, and network settings can speed up future replacements. This documentation also reduces the risk of selecting an adapter that fits mechanically but does not support the required system configuration.

Selection Checklist Before Ordering

• Confirm the full model designation: RECA-01.
• Verify product ID 3ABD0000045102 against the existing part or approved bill of materials.
• Confirm the target ABB drive supports this option module.
• Check the required EtherCAT communication functions and controller compatibility.
• Verify the drive parameter setup and any firmware requirements.
• Check network cable type, connector condition, topology, and segment length.
• Confirm enclosure protection and ambient conditions.

Packaging, Warranty, and Shipping

Frequently Asked Questions

Q1: Does the RECA-01 require an external power supply?

No. The drive control board supplies the adapter with 5 V DC. The specified average current consumption is 290 mA. Confirm the host drive's support for the module before installation.

Q2: Can I connect the RECA-01 directly to a standard Ethernet switch?

Do not assume standard Ethernet switching equipment will support the intended EtherCAT network architecture. Follow the EtherCAT master and topology requirements for the specific system. Verify network device roles before adding switches or other equipment.

Q3: How can I distinguish an adapter problem from a network configuration problem?

Check the drive's recognition of the option module first. Then review the EtherCAT master diagnostics, network connections, and parameter settings. Compare the results with a known-good configuration where possible.

Q4: What should I check when planning a longer EtherCAT cable route?

Keep each segment within the specified 100 m limit. Confirm the cable category, installation environment, connector quality, and network topology. Include the actual cable path in the design rather than relying only on straight-line equipment distances.

Q5: What information should I send when requesting a replacement quotation?

Provide the adapter model, product ID, exact ABB drive model, firmware details when available, and the intended EtherCAT application. A clear nameplate photo and existing installation details can help the supplier verify the correct part.
