Manufacturer: SICK
Product No.: DT50-2B215552
Condition： En stock
Product Type: Laser Distance Sensor
Product Origin: DE
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Cantidad

Selected quantity: 1

Tiempo estimado de entrega: 12-26 días (Internacional), 3-6 días (Estados Unidos).

Devolución dentro de los 30 días siguientes a la compra. Los aranceles e impuestos no son reembolsables.

Pago Seguro Garantizado

Engineering Insight & Core Overview

The DT50-2B215552 is an advanced mid-range laser distance sensor manufactured by SICK within the high-performance Dx50-2 Series. Powered by patented HDDM time-of-flight technology, this diffuse-mode sensor provides reliable, high-speed dimensional measurement across demanding factory environments.

According to Global PLC Spare HUB's Insight, automation engineers regularly implement the DT50-2B215552 in high-throughput material handling applications where target reflectivity fluctuates. Our hands-on field evaluations show that utilizing IO-Link configuration parameters alongside proper M12 connector shielding drastically eliminates measurement jitter caused by ambient electrical noise.

Technical Parameters & Performance Metrics

Brand & Series: SICK Dx50-2 Series (Alternate Mfr Part No: 1075271)
Model Number: DT50-2B215552
Measurement Range: 200 mm to 30,000 mm on white targets (up to 10,000 mm on dark targets)
Resolution & Accuracy: 0.1 mm measurement resolution with an absolute accuracy of +/- 7 mm
Response Time & Speed: Variable response times from 1.67 ms up to 150 ms depending on the selected speed profile (Super Fast to Super Slow)
Interface & Supply: Equipped with IO-Link communication interface, operating on 10-30 VDC supply voltage
Enclosure & Build: Rugged die-cast zinc housing with PMMA acrylic glass optics, rated at IP65/IP67 ingress protection

Integration, Diagnostics & Operational Convenience

Visual Diagnostics: Features 3 onboard status LEDs and an integrated LC display with an intuitive menu structure for fast on-site error tracking.
Electrical Connection: Standard 5-pin M12 male connector layout designed for secure plug-and-play industrial integration.
Diagnostic Capabilities: Real-time distance tracking and built-in shape comparison features allow the sensor to self-monitor object positioning anomalies.

Global Logistics, Express Shipping & Warranty

Express Global Dispatch: Shipped within 24 to 48 hours via trusted tier-one courier services including FedEx, UPS, and DHL.
Warranty Terms: Backed by a comprehensive 12-month replacement warranty covering non-artificial operational failures.

Typical Industrial Application Scenarios

Automated Storage & Retrieval Systems (AS/RS): Precise vertical and horizontal crane positioning inside high-bay warehouses.
Automotive Manufacturing: Continuous loop level monitoring and body-in-white component clearance verification.
Packaging & Conveyor Lines: High-speed object profiling, leading-edge detection, and collision avoidance on long-span sorting belts.

Frequently Asked Questions

What is the maximum detection range of the DT50-2B215552 sensor?
It measures up to 30,000 mm on high-reflectivity white targets and up to 10,000 mm on low-reflectivity dark surfaces.

How can I change response time and measurement speed settings on site?
You can configure speed profiles directly through the integrated LC display menu structure or remotely via the IO-Link interface.

What should I check if the sensor exhibits erratic readings in dusty environments?
Inspect the PMMA acrylic glass front lens for dust accumulation and utilize the onboard diagnostics LEDs or LC display to check signal remission feedback.

Buying Guide: When should I choose the Dx50-2 series over standard photoelectric sensors?
Choose the DT50-2B215552 when your application requires precise, continuous millimeter-level distance tracking over long mid-range spans rather than simple binary presence detection.

Does the sensor require specialized configuration software for basic deployment?
No, basic parameters, threshold adjustments, and teaching can be handled directly on the device using its built-in LC display and control buttons.
