LMS500-21000 SICK Indoor High-Resolution LiDAR Sensor | Shop Now

Global PLC Spare HUB's Insight

Precision distance measurement in dusty or complex indoor environments demands exceptional optical filtering and high scanning frequencies.

The LMS500-21000 2D LiDAR scanner delivers remarkable detection accuracy across an impressive 80-meter working range.

Engineers integrating SICK Sensors rely on this Lite variant for high-speed object profiling and reliable automation tasks.

Field experience shows that leveraging the built-in fog and particle filters drastically reduces false triggers in harsh indoor spaces.

For instance, automated guided vehicles use this scanner to map dynamic paths and detect obstacles instantly.

Technical Specifications & Performance Parameters

Ideal Equipment Compatibility & Application Scenarios

• Compatible with standard industrial Ethernet (TCP/IP, UDP/IP) and serial networks.
• Deployed on Automated Guided Vehicles (AGVs) for precise collision avoidance.
• Integrated into automated warehousing logistics for high-speed object profiling.
• Utilized in security and access monitoring fields for perimeter intrusion detection.
• Mounted on material handling cranes for automated cargo dimensioning.

System Diagnostics & Fault Troubleshooting

• Onboard 7-segment display and 5 status LEDs indicate real-time operational health.
• Mini-USB service interface streamlines diagnostic data extraction and firmware configuration.
• Built-in echo, glare, and particle filters isolate real targets from ambient interference.
• Ethernet host connection allows remote monitoring of scan field evaluation states.

Logistics, Fulfillment & Warranty Terms

• Lightning-fast dispatch processed within 24 to 48 hours globally.
• Shipped securely via trusted premium carriers including FedEx, UPS, and DHL.
• Backed by our comprehensive 12-month operational service warranty.

Frequently Asked Questions & Expert Buying Guide

Q: Can the LMS500-21000 be used for safety-rated applications?

A: No, this specific sensor model does not constitute a safety component as defined by machine safety legislation.

Q: How do the built-in optical filters handle dusty indoor environments?

A: The unit features integrated fog, particle, and average filters that actively suppress airborne dust noise to maintain accurate readings.

Q: What communication protocols are supported for data output?

A: It supports Ethernet (TCP/IP, UDP/IP), RS-232, RS-422 serial lines, and a dedicated Mini-USB service port.

Q: Buying Guide Tip: How do I select the right scanning frequency for my application?

A: Choose higher scanning frequencies (up to 75 Hz) when tracking fast-moving targets like high-speed AGVs, or lower frequencies for stationary profiling.

Q: Field Insight: What precautions are necessary regarding ambient light immunity?

A: While the unit offers 70,000 lx ambient light immunity, direct exposure to high-intensity sunlight should be avoided since it is designed primarily for indoor use.
