TCSESM083F2CU0 Schneider Electric ConneXium Managed Switch 6TX 2FX
Manufacturer: Schneider Electric
Product No.: TCSESM083F2CU0
Condition： In stock
Product Type: Managed Switch
Product Origin: DE
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Overview
The TCSESM083F2CU0 is a Schneider Electric ConneXium industrial managed Ethernet switch.
It features six 10/100BASE-TX copper ports and two 100BASE-FX multimode SC fiber ports.
Engineers deploy this Transparent Ready unit for high-availability control network architectures.
The switch supports fault-tolerant ring topologies with up to 50 switches per ring.
Dual power inputs protect mission-critical automated processes against power source failures.
Technical Specifications
The following MECE table outlines core parameters for the TCSESM083F2CU0 managed switch:
| Category | Specification Parameter | Details & Engineering Values |
|---|---|---|
| Identity & Build | Brand & Series | Schneider Electric ConneXium Series |
| Model Part Number | TCSESM083F2CU0 | |
| Mounting & Enclosure | 35 mm symmetrical DIN rail mount, IP20 rated | |
| Network Ports | Copper Interface | 6 x RJ45 ports (10BASE-T/100BASE-TX shielded) |
| Fiber Optic Interface | 2 x Duplex SC ports (100BASE-FX multimode) | |
| Fiber Attenuation | 11 dB (62.5/125 μm) / 8 dB (50/125 μm) | |
| Protocols & Redundancy | Ethernet Services | VLAN, IGMP Snooping, Multicast Filtering, RSTP |
| Security Features | SMTP V3, Secure Port, Priority Port management | |
| Ring Redundancy | Redundant single ring, max 50 switches in ring | |
| Network Cascade Limit | Unlimited switches in cascade formation | |
| Electrical & Physical | Supply Voltage Range | 18...30 V AC SELV / 9.6...60 V DC SELV |
| Power Consumption | 7.7 W maximum operational load | |
| Alarm Relay Output | 1 volt-free contact (1 A rating) |
Compatible Equipment & Application Scenarios
The TCSESM083F2CU0 switch links essential industrial automation hardware seamlessly across plant sites:
- Schneider Electric Modicon PLCs: Integrates Modicon M580 and M340 controllers into Ethernet architectures.
- Industrial HMI Panels: Connects Magelis operator touchscreens to main field control cabinets.
- Water & Wastewater Treatment: Bridges remote pumping stations over long-distance optical fiber links.
- Energy Distribution Facilities: Provides secure Ethernet communications across high-noise electrical substations.
Diagnostic Capabilities
Built-in visual indicators and firmware tools simplify active network monitoring for technicians:
- Dedicated LED indicators display power supply states P1 and P2 in real time.
- Individual channel status and activity LEDs verify copper link performance instantly.
- Integrated Ring Manager and Stand-by LEDs simplify optical ring troubleshooting.
- Internal alarm relay trips automatically during power loss or cable disconnection events.
Global PLC Spare HUB Insights & Field Experience
Engineers at Global PLC Spare HUB frequently integrate ConneXium managed switches into SCADA rings.
Proper fiber attenuation calculation prevents transceiver overload and optical signal degradation.
Field Case Example: A municipal water plant experienced fiber network drops during pump starts. Engineers installed the TCSESM083F2CU0 switch in a redundant single ring configuration. Reconfiguring RSTP settings reduced recovery time below 30 milliseconds during line cuts. The 11 dB optical power margin maintained clean data packet streaming across distances.
Selection Guide
Review these operational requirements to select the correct switch module for your project:
- Media Requirement: Choose this model when mixing six local copper lines with two fiber runs.
- Fiber Type Check: Confirm your optical field cables use multimode glass fiber with SC connectors.
- Power Flexibility: Verify whether your cabinet provides 24 V DC or 24 V AC power sources.
- Redundancy Level: Select managed units when fast ring self-healing and SNMP telemetry are required.
Package List, Warranty & Logistics
Every shipment contains fully inspected factory components ready for immediate installation:
- 1 x Schneider Electric TCSESM083F2CU0 Switch Assembly
- 1 x Removable 6-Way Terminal Block Power Connector
- 12-Month Comprehensive Warranty: Protects against functional hardware defects.
- Rapid Dispatch Shipping: Dispatches within 24 to 48 hours via FedEx, UPS, or DHL express.
Frequently Asked Questions (FAQ)
Q1: What optical fiber connector type does the TCSESM083F2CU0 switch require?
A: The two multimode fiber ports utilize standard Duplex SC optical connectors.
Q2: Does the switch support redundant DC power supply connections?
A: Yes, the removable 6-way connector accepts dual 9.6 to 60 V DC inputs.
Q3: Can this switch function as the primary Ring Manager in a redundant ring?
A: Yes, onboard firmware allows configuration as Ring Manager or Ring Redundancy member.
Q4: How does field experience guide fiber cleaning before installation?
A: Field engineers recommend cleaning SC optical ferrule tips to maintain full 11 dB attenuation budgets.
Q5: What carrier choices are available for international emergency replacement orders?
A: We ship orders worldwide using premium air express options via FedEx, DHL, or UPS.
