IC697ALG230 Emerson GE Fanuc PLC Analog Input Converter Module
Manufacturer: GE Fanuc
Product No.: IC697ALG230
Condition： In stock
Product Type: Analog Input Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Product Introduction
The GE Fanuc IC697ALG230 Base Converter Module belongs to the Series 90-70 PLC platform.
It provides high-accuracy analog signal conversion for industrial control systems.
The module supports eight differential analog input channels.
Each channel supports voltage or current signal configuration.
The module works with IC697ALG440 voltage expanders and IC697ALG441 current expanders.
The system supports scalable analog measurement applications.
Engineers use this module for process monitoring and automation control.
The IC697ALG230 uses differential wiring technology.
This design improves signal stability in industrial environments.
It reduces measurement errors caused by electrical noise.
Global PLC Spare HUB Review shows strong field value for this module.
Engineers often select it for reliable analog acquisition projects.
A typical field example involves monitoring pressure transmitters in a refinery unit.
The module receives 4-20 mA signals from transmitters.
The PLC system then processes real-time process data.
Technical Specifications
| Parameter | Specification |
| Brand | GE Fanuc (Current support under Emerson Automation) |
| Series | Series 90-70 PLC |
| Model Number | IC697ALG230 |
| Module Type | Analog Base Converter Module |
| Input Channels | 8 differential analog inputs |
| Signal Type | 4-20 mA current input and -10 VDC to +10 VDC voltage input |
| Measurement Range | Voltage: -10 VDC to +10 VDC |
| Measurement Range | Current: 0 mA to 22.5 mA, default 4-20 mA |
| Resolution | 16-bit analog input resolution |
| Update Rate | 2.4 ms to 2.8 ms |
| Frequency Response | Fast analog sampling with channel filtering |
| Response Time | 0.1% accuracy response within 67 milliseconds |
| Response Time | 0.5% accuracy response within 51 milliseconds |
| Response Time | 1.0% accuracy response within 42 milliseconds |
| Response Time | 5.0% accuracy response within 30 milliseconds |
| Voltage Accuracy | ±0.01% full scale and ±0.02% value |
| Current Accuracy | ±0.05% full scale and ±0.1% value |
| Linearity | ±0.02% full scale across measurement range |
| Temperature Coefficient | Voltage: typical ±5 PPM/°C |
| Temperature Coefficient | Voltage maximum ±15 PPM/°C |
| Temperature Coefficient | Current maximum ±30 PPM/°C |
| Calibration | Factory calibrated at 10 volts ±2 mV |
| Power Requirement | 0.8 A at +5 VDC, approximately 4 watts |
| Terminal Type | 40-pin removable terminal block |
| Wiring Method | Differential wiring configuration |
| Environmental Capability | Designed for industrial PLC control environments |
| Noise Protection | Opto-isolation and channel filtering improve interference resistance |
Core Technical Features
- Eight-channel differential analog acquisition supports flexible signal monitoring.
- 16-bit resolution provides accurate process measurement.
- Individual channel configuration simplifies engineering setup.
- Low-pass filtering improves signal quality.
- Optical isolation protects PLC backplane communication.
- Expansion capability supports larger analog systems.
Compatibility Information
| Compatible Product | Description |
| IC697ALG440 | Voltage Expander Module |
| IC697ALG441 | Current Expander Module |
| Series 90-70 PLC | Main PLC platform compatibility |
The base module supports up to seven expander modules.
The complete system can reach up to 120 analog inputs.
Installation Guide
- Install the module into the compatible Series 90-70 rack.
- Confirm PLC power isolation before installation.
- Connect field signals through the removable terminal block.
- Use shielded cables for sensitive analog signals.
- Verify correct voltage and current channel settings.
- Install expander modules through the expansion interface.
Differential wiring requires two reference wires per input channel.
This wiring method improves EMI resistance in industrial locations.
Commissioning and Maintenance Advantages
- The configuration software simplifies channel parameter setup.
- Engineers can adjust scaling values through PLC logic.
- Channel diagnostics support troubleshooting activities.
- CPU alarms provide abnormal condition notifications.
- Fault reporting improves maintenance efficiency.
Global PLC Spare HUB's Insight highlights practical maintenance benefits.
Field technicians often check signal range first during commissioning.
For example, a 4-20 mA loop test quickly identifies wiring issues.
The module allows engineers to compare expected and actual values.
Diagnostic Capability
- Channel-level fault reporting supports fast troubleshooting.
- Input monitoring helps detect abnormal signals.
- Configuration data assists system verification.
- Signal filtering reduces unstable readings.
- Expansion communication status improves system diagnosis.
Typical Applications
| Industry | Application Example |
| Oil and Gas | Pressure, flow, and level transmitter monitoring |
| Power Generation | Analog equipment condition monitoring |
| Water Treatment | Pump and process parameter control |
| Manufacturing | Machine automation signal acquisition |
| Chemical Processing | Process variable measurement systems |
Certification and Quality Information
- Manufactured for GE Fanuc industrial automation platforms.
- Designed for industrial PLC system integration.
- Quality inspection supports reliable field deployment.
- Packaging inspection ensures safe transportation.
Package Contents
- IC697ALG230 Base Converter Module ×1
- Removable terminal block ×1
- Product documentation support
- Protective industrial packaging
Shipping and Warranty
- Fast delivery options include FedEx, UPS, and DHL.
- Standard shipping preparation takes 24-48 hours.
- Professional packaging protects industrial components.
- Warranty period: 12 months.
- Technical support assists product application questions.
FAQ
Q: What PLC system uses the IC697ALG230?
A: The module works with the GE Fanuc Series 90-70 PLC platform.
Q: How many analog inputs does this module provide?
A: It provides eight differential analog input channels.
Q: Can the module measure both voltage and current signals?
A: Yes, each channel supports configurable voltage or current measurement.
Q: Which expander modules work with this model?
A: It supports IC697ALG440 voltage expanders and IC697ALG441 current expanders.
Q: What field experience helps during installation?
A: Engineers should verify loop wiring before changing software settings.
A common issue involves incorrect polarity on differential inputs.
Q: How do technicians improve measurement stability?
A: Technicians usually use shielded cables and proper grounding methods.
Q: What should buyers confirm before purchase?
A: Buyers should confirm PLC rack compatibility, signal type, and channel requirements.
Q: Is expansion important for future upgrades?
A: Yes, expansion modules provide additional channels for system growth.
Selection Guide
- Select IC697ALG230 for Series 90-70 analog input applications.
- Confirm required voltage or current measurement ranges.
- Check available PLC rack resources before installation.
- Choose expander modules for larger analog systems.
- Review environmental conditions before field deployment.
The GE Fanuc IC697ALG230 provides reliable analog conversion for demanding automation systems.
