IC693MDL748 GE Fanuc Series 90-30 Digital Output New

Product Overview

The IC693MDL748 is an 8-point digital output module.

It belongs to the GE Fanuc Series 90-30 PLC platform.

This positive logic module controls field devices requiring 24 to 48 VDC power.

Transistor outputs deliver up to 0.5 Amps per point efficiently.

Dual internal 3.15 Amp fuses protect against field overcurrent faults.

Configuration & Technical Breakdown

• IC693MDL748 — Positive Logic Digital Output Module
  • Platform Compatibility — GE Fanuc Series 90-30 PLCs
  • Channel Density — 8 sourcing transistor output points
  • Voltage Rating — 24 VDC to 48 VDC output range
  • Current Rating — 0.5 Amps load current per point
  • Backplane Draw — 110 mA at 5 VDC supply voltage
  • Protection System — Two 5x20mm 3.15A fast-acting fuses
  • Wiring Interface — 20-screw removable terminal block with holding screws

Technical Specifications

Installation & Fuse Replacement Guidelines

• Insert the module securely into any standard Series 90-30 baseplate slot.
• Loosen the front holding screws before removing the 20-pin terminal block.
• Wire field devices to the screw terminals using recommended wire gauges.
• Tighten terminal board holding screws to 8 to 10 in-lb of torque.
• Replace blown fuses with equivalent Littelfuse 2173.15 or Bussmann GDB-3.15A units.

Compliance & Warranty Terms

• Manufactured under ISO quality standards for reliable industrial automation performance.
• Backed by a comprehensive 12-Month factory warranty covering operational reliability.

Package Contents & Express Delivery

• 1 x GE Fanuc IC693MDL748 Digital Output Module
• 1 x 20-Screw Removable Terminal Block with retention screws
• Dispatch time within 24 to 48 hours after order confirmation.
• Fast worldwide shipping via FedEx, UPS, and DHL express networks.

Typical Application Scenarios & Diagnostics

• Drives 24V and 48V DC solenoid valves on packaging machinery.
• Controls indicator lights and alarm horns on operator panels.
• Actuates intermediate control relays in industrial motor starter panels.
• Individual LED indicators display real-time logic status for fast field diagnostics.

Global PLC Spare HUB's Insight

High machinery vibration often loosens standard PLC terminal blocks over time.

During a stamping press audit, intermittent valve dropping caused unexpected line shutdowns.

Technicians discovered loose terminal contacts caused by continuous cabinet vibration.

The IC693MDL748 prevents this issue with dedicated terminal board holding screws.

Always torque holding screws to 8-10 in-lb to ensure solid electrical contact.

Frequently Asked Questions (FAQ)

Q: What replacement fuse models fit the IC693MDL748 module?

A: Use 5x20mm 3.15A fast-acting fuses like Littelfuse 2173.15 or Bussmann GDB-3.15A.

Q: How does operating voltage affect the ambient temperature rating?

A: The module supports up to 60°C at 50 VDC, but reduces to 50°C at 60 VDC.

Q: Can I replace the terminal block without disconnecting field wiring?

A: Yes, loosen the holding screws to remove the wired terminal block completely.

Q: How do I select between positive logic and negative logic output modules?

A: Choose positive logic modules when field loads require sourcing current from the module.

Q: What is the recommended torque setting for the terminal board holding screws?

A: Tighten holding screws to 8 to 10 in-lb torque to resist vibration.
