Bently Nevada 330130-060-03-05 3300 XL 6m Armored Extension Cable
Manufacturer: Bently Nevada
Product No.: 330130-060-03-05
Condition： In stock
Product Type: Extension Cable
Product Origin: USA
Payment: T/T, Western Union
Weight: 618g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Bently Nevada 330130-060-03-05 Overview
The Bently Nevada 330130-060-03-05 is a high-performance 6.0-meter armored extension cable designed for the 3300 XL 8mm Proximity Transducer System. It connects proximity probes to Proximitor sensors with absolute precision. Engineering teams deploy this robust cable in demanding industrial environments where reliable machinery protection and vibration monitoring are critical. The integrated stainless steel armor protects signal integrity against harsh mechanical stress and fluid exposure.
Technical Specifications
| Brand | Bently Nevada |
| Model Number | 330130-060-03-05 |
| Product Series | 3300 XL Series |
| Product Type | Armored Extension Cable with Connector Protector |
| Cable Length | 6.0 meters (19.7 feet) |
| Armored Cable Weight | 103 g/m (1.5 oz/ft), 0.618 kg total |
| Core DC Resistance (RCORE) | 1.32 ± 0.21 Ω |
| Jacket DC Resistance (RJACKET) | 0.39 ± 0.08 Ω |
| Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Connector Type | Gold-plated ClickLoc connectors |
| Linear Measurement Range | 2.0 mm (80 mils), from 0.25 mm to 2.3 mm target gap |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ±5.6% nominal |
| Frequency Response | 0 to 10 kHz (+0, -3 dB typical) |
| Resolution & Sensitivity | Sub-micron resolution; supply sensitivity under 2 mV/V |
| Power Requirements | -17.5 Vdc to -26 Vdc at 12 mA maximum |
| Output Resistance | 50 Ω |
| Operating Temperature | -51°C to +177°C (-60°F to +350°F) for probe/cable |
| Environmental Resistance | IEC 68-2-3 humidity rated (<3% ASF change over 56 days) |
| Hazardous Area Approvals | CSA, ATEX, IECEx certified (Option 05) |
| Country of Origin | Made in U.S.A. |
System Compatibility Guidelines
- Matches all Bently Nevada 3300 XL 8mm proximity probes and sensors seamlessly.
- Supports legacy standard 3300 5mm and standard 3300 8mm non-contacting probe systems.
- Requires total system electrical length equal to 5.0m, 7.0m, or 9.0m configurations.
- Integrates directly with standard 3-conductor shielded triad field wiring up to 305 meters.
Installation, Maintenance & Diagnostics
- Connector Protection: Pre-installed connector protector prevents liquid ingress and mechanical damage during operation.
- ClickLoc Mechanism: Audible click verifies positive connection tightness between probe and cable.
- Cable Pull Strength: Patented CableLoc design provides 330 N (75 lbf) pull strength.
- Field Diagnostics: Check center conductor resistance (1.32 Ω nominal) to verify cable integrity.
- Silicone Tape Notice: Use included silicone tape only when turbine oil exposure is absent.
Typical Application Scenarios
- Turbine shaft vibration monitoring and radial bearing position measurement.
- High-speed centrifugal compressor axial displacement tracking in oil refineries.
- Gearbox shaft centerline movement monitoring under high moisture conditions.
- Boiler feed pump vibration diagnostics in power generation facilities.
Ordering & Fast Shipping Terms
- Condition & Warranty: 100% genuine original product with comprehensive 12-month warranty.
- Dispatch Time: Ships within 24 to 48 hours after order verification.
- Global Carriers: Express worldwide delivery via FedEx, UPS, and DHL.
Global PLC Spare HUB's Insight
In field applications across turbomachinery installations, extension cables face extreme physical stress and oil mist exposure. Our engineering team frequently observes signal noise issues caused by loose non-armored cables or compromised connectors. The Bently Nevada 330130-060-03-05 solves these field challenges effectively. During a recent maintenance outage at a combined-cycle power plant, replacing degraded unarmored lines with this exact 3300 XL armored variant eliminated spurious vibration spikes caused by cable whipping near the turbine housing. The pre-installed connector protector ensured zero oil penetration, securing continuous 24/7 diagnostic reliability.
Selection & Buying Guide
- System Length Match: Ensure your probe length plus extension cable length matches your Proximitor sensor calibration.
- Armor Requirement: Choose option 03 for exposed conduit runs to prevent physical crushing.
- Hazardous Zones: Select option 05 when operating in explosive environments requiring ATEX or IECEx safety compliance.
Frequently Asked Questions (FAQ)
Q1: What does option 03 represent in part number 330130-060-03-05?
A1: Option 03 specifies armored stainless steel cable equipped with a pre-installed connector protector.
Q2: Can I use silicone tape in turbine oil environments?
A2: No, silicone tape is not recommended for applications exposing connections directly to turbine oil.
Q3: How do I verify if my 330130 cable has an internal open circuit?
A3: Measure center conductor resistance using a multimeter; it should read approximately 1.32 Ω for 6-meter cables.
Q4: What dispatch timeline can I expect for urgent plant repairs?
A4: We dispatch orders within 24 to 48 hours using express carriers like FedEx, UPS, or DHL.
Q5: What warranty coverage applies to this Bently Nevada cable?
A5: All orders include a full 12-month replacement warranty for engineering peace of mind.
