Bently Nevada 330104-00-06-90-12-05 Proximity Probe 3300 XL Series

Industrial Precision: The 330104-00-06-90-12-05 Proximity Transducer

The 330104-00-06-90-12-05 3300 XL 8mm Proximity Probe is the industry standard for high-accuracy vibration and position monitoring in critical rotating machinery. Manufactured by Bently Nevada, this transducer system ensures exceptional linearity and interchangeability, making it indispensable for turbine, compressor, and pump diagnostics.

Configuration Breakdown

• 330104: 3300 XL 8mm Probe, M10x1 Thread, Armor-protected
• 00: Unthreaded Case Length (00 mm)
• 06: Overall Case Length (60 mm)
• 90: Total System Length (9.0 meters)
• 12: Connector/Cable: Miniature Coaxial ClickLoc, FluidLoc Cable
• 05: Approvals: CSA, ATEX, IECEx Certified

Technical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case: AISI 303/304 Stainless Steel (SST)
• DC Resistance: 9.87 ± 0.50 Ω
• Pressure Rating: Viton O-ring sealed (Differential pressure rated)
• Operational Temp: -55°C to +232°C (Refer to temperature classification schedule)

Global PLC Spare HUB's Insight

In our technical analysis, the 330104-00-06-90-12-05 is engineered for extreme environment reliability. The combination of the FluidLoc cable and armor protection prevents oil migration and mechanical abrasion, which are common failure points in legacy probe installations. We recommend this specific configuration for hazardous areas requiring ATEX/IECEx compliance where high-temperature rating (T1) is critical.

Model Comparison & Selection Advice

Comparison: 330104-04-09-50-02-05
While both modules belong to the 3300 XL series, your selected model (9.0m length) is optimized for long-distance routing in large turbine enclosures, whereas the 330104-04-09-50-02-05 variant is designed for compact cabinet integration. Technical Advice: Always ensure system length (probe + extension cable) matches your initial calibration to maintain 200 mV/mil accuracy.

Logistics & Warranty

• Warranty: 12-month performance assurance.
• Global Logistics: Expedited dispatch via FedEx, UPS, and DHL.
• Fulfillment: Orders processed within 24-48 hours.

Expert FAQ

Why is the 9.0m cable length critical for system performance?
Bently Nevada proximity systems are calibrated as a matched set; the 9.0m length accounts for specific impedance; changing the length without recalibration compromises measurement accuracy.

Can I use this probe with a non-3300 XL Proximitor?
No; interchangeability specifications apply strictly to systems consisting solely of 3300 XL components to ensure consistent 50 Ω output.

What is the purpose of the "FluidLoc" cable design?
FluidLoc cable prevents oil/fluids from migrating through the cable bundle into the junction box, a common cause of terminal corrosion in industrial machines.

How should I handle the probe tip during installation?
The PPS tip is delicate; avoid impact and ensure the gap is set to 1.27 mm (50 mils) to maintain the linear operating range.

Selection Guide:
If your application experiences heavy vibration, prioritize the armored 330104 series over unarmored variants to protect against mechanical fatigue and cable breakage.
