21000-16-05-15-072-03-02 Bently Nevada Proximity Probe Assembly
Manufacturer: Bently Nevada
Product No.: 21000-16-05-15-072-03-02
Condition： In stock
Product Type: Proximity Probe Housing Assembly
Product Origin: USA
Payment: T/T, Western Union
Weight: 1100g
Shipping port: Xiamen
Warranty: 12 months
Estimate delivery times: 12-26 days (International), 3-6 days (United States).
Return within 30 days of purchase. Duties & taxes are non-refundable.
Guaranteed Safe Checkout
Engineering Overview & System Architecture
The 21000-16-05-15-072-03-02 proximity probe housing assembly engineered by Bently Nevada provides robust mechanical protection for rotating machinery sensor elements. As part of the 21000 Proximity Probe Housing Assemblies series, this configuration integrates an 8 mm reverse mount probe with precise standoff dimensions for critical vibration monitoring applications.
Configuration Breakdown & Suffix Architecture
| Suffix Code Element | Designation Parameter | Engineering Specification |
|---|---|---|
| Base Model | Housing Platform | Bently Nevada 21000 Series Assembly |
| 16 | Probe Option | 3300 XL 8 mm probe with integral connector |
| 05 | Cable Length Option | 0.5 m (20 in) probe coaxial cable length |
| 15 | Standoff Adapter | 1.5 in (38 mm) mechanical standoff adapter |
| 072 | Probe Penetration (Option D) | 7.2 inches total probe penetration dimension |
| 03 | Fittings Option | 3/4-14 NPT plug, reducer, and multi-size cable seal grip |
| 02 | Mounting Thread | 3/4-14 NPT standard casing mounting thread |
Technical Specifications Matrix
- Manufacturer & Model: Bently Nevada 21000-16-05-15-072-03-02
- Body Construction: Aluminum housing body with 304 stainless steel sleeve
- Assembly Mass: Approximately 1.1 kg (2.4 lb) typical weight without conduit fittings
- Penetration Limits: Combined C plus D penetration reaches up to 17.0 inches with visible flag label
- Electrical Compliance: FCC Part 15 subpart B compliant and RoHS Directive 2011/65/EU certified
- Hazardous Approvals: CSA explosion-proof certified for Class I, Div 1/2 and Class II environments
Compatible Rotating Equipment & Application Scenarios
The 21000-16-05-15-072-03-02 assembly integrates directly with API 670 compliant machinery protection systems. Typical high-reliability industrial deployment environments include:
- Large steam turbines and gas expansion compressors requiring exact radial vibration tracking.
- Heavy-duty centrifugal pumps operating in hazardous refinery processing zones.
- Multistage industrial blowers and heavy gearboxes monitored by eddy-current transducers.
Advanced Diagnostic Capabilities
The assembly design allows vibration analysts to measure shaft dynamic motion and axial position with sub-micron resolution. Early detection of rotor unbalance, oil whirl, and shaft rub prevents catastrophic machinery failure. The robust housing shields sensitive high-frequency signals from severe electromagnetic interference in plant environments.
Global Logistics, Fulfillment & Warranty Terms
- Expedited Dispatch: Stock orders process and dispatch within 24 to 48 hours of confirmation.
- International Carriers: Secure worldwide air transit via FedEx, UPS, and DHL.
- Quality Protection: Fully covered by a standard 12-month factory manufacturing warranty.
Global PLC Spare HUB's Insight
Machinery engineers often encounter high-frequency resonance issues when installing extended probe penetrations on high-speed turbines. Field experience shows that adding intermediate sleeve supports when combined penetration depths exceed 12 inches completely eliminates false vibration spikes. For instance, a Gulf Coast refinery stabilized its critical compressor monitoring network by replacing rigid unanchored probes with the robust 21000-16-05-15-072-03-02 housing assembly, ensuring uninterrupted API 670 compliance.
Model Selection & Technical Comparison Guide
Evaluating alternative housing configurations ensures optimal mechanical fit for your specific machine case clearance. Review the technical comparison below:
| Model Number | Probe & Cable Option | Penetration Depth | Engineering Recommendation |
|---|---|---|---|
| 21000-16-05-15-072-03-02 (Current Model) | 3300 XL 8 mm (0.5 m cable) | 7.2 inches total penetration | Optimal for deep-set machine case penetrations requiring CSA explosion-proof enclosures. |
| 21000-28-10-15-030-04-02 | Alternative Probe Option | Shorter penetration variant | Recommended for shallow mounting cases with restricted radial installation clearances. |
Professional Frequently Asked Questions
Question: Why must instrument technicians verify counter-boring requirements on machine cases when installing the 21000-16-05-15-072-03-02?
Answer: For probe penetration lengths between 1.0 and 2.0 inches, counter-boring prevents housing side-view or rear-view interference effects from distorting eddy-current signals.
Question: How does the CSA Type 4 enclosure rating impact outdoor compressor installations?
Answer: The Type 4 rating ensures complete protection against windblown dust, rain, and hose-directed water ingress in exposed offshore platform environments.
Question: What specific precaution applies when probe penetration lengths exceed 300 mm (12 in)?
Answer: Installers must add rigid sleeve support near the probe tip to prevent harmonic resonance from damaging the internal mechanical structure.
Question: Can maintenance personnel access the probe serial number once the housing is fully mounted?
Answer: Yes, probe part numbers and serial numbers are displayed on an external flag label secured to the visible section of the probe cable.
Question: What thread sealant specification is required for the 3/4-14 NPT conduit entries?
Answer: Technicians must apply a certified non-hardening thread lubricant compliant with hazardous area explosion-proof installation codes.
